Country of origin | China |
Package volume | 3399.38 cm³ |
Extended display identification data (EDID) | Yes |
Electrostatic Discharge (ESD) protection | Yes |
High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
Maximum Resolution | 3840 x 2160 pixels |
Cable types supported | Cat7 |
Type | Transmitter & receiver |
Bandwidth | 18 Gbit/s |
Material | Metal |
HDCP version | 2.2 |
Maximum transfer distance | 100 m |
HDCP | Yes |
HDCP & EDID bypass | Yes |
Maximum refresh rate | 60 Hz |
Product colour | Black |
High Dynamic Range (HDR) supported | Yes |
Bidirectional | Yes |
Operating voltage (receiver) | 24 V |
Power source type | DC |
Power consumption (receiver) (max) | 10 W |
Power Over Ethernet (PoE) | No |
External power adapter | Yes |
Power consumption (transmitter) (max) | 10 W |
Operating voltage (transmitter) | 24 V |
Operating temperature (T-T) | 0 - 40 °C |
Receiver dimensions (WxDxH) | 140 x 65 x 18 mm |
Transmitter weight | 246 g |
Receiver weight | 246 g |
Transmitter dimensions (WxDxH) | 140 x 65 x 18 mm |
Package width | 245 mm |
PACKAGE WEIGHT | 1.09 kg |
Package depth | 185 mm |
Package height | 75 mm |
Manual | Yes |
CABLES INCLUDED | USB |
AC adapter included | Yes |
RJ-45 output ports | 1 |
Remote (IR) output | 2 |
Remote (IR) input | 2 |
USB connector type | USB Type-A |
HDMI version | 2.0b |
USB version | 1.1 |
RJ-45 input ports | 1 |
Number of HDMI outputs | 1 |
USB ports quantity | 6 |
HDMI in | 1 |
Connectivity Technology | Wired |
DC-in jack | Yes |
UK Trade Tariff code | 85176200 |
