| Technical details | |
| transmission technology | Kabelgebunden |
| Eigenschaft | Statische IP |
| Maximum number of supported cameras | 1 |
| Video-Codec | H.264 |
| Camera | |
| Megapixel (ca.) | 2 MP |
| Supported video modes | 720p, 1080p |
| Sensor-Typ | CMOS |
| Image sensor size | 25,4 / 5 mm (1 / 5") |
| minimum lighting | 40 Lux |
| angle of view, horizontal | 63,3° |
| angle of view, vertical | 49,6° |
| Audio | |
| number of speakers | 1 |
| Lautsprecherleistung | 1 W |
| voice codec | G.711a, G.711u, G.723, G.726-32, G.729A, G.729B, G.729ab, iLBC |
| Design | |
| Product color | Schwarz, Silber |
| International degree of protection (IP code) | IP54 |
| housing material | Acrylnitril-Butadien-Styrol (ABS) |
| Unterstützte Positionierung | Senkrecht |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| Ethernet LAN data transfer rates | 10,100 Mbit/s |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| management functions | |
| energy | |
| power supply output voltage | 12 V |
| AC adapter output current | 1 A |
| operating conditions | |
| operating temperatur | -20 - 50 °C |
| Storage temperature range | -30 - 60 °C |
| Operating relative humidity | 10 - 95% |
| weight and dimensions | |
| broad | 88 mm |
| depth | 88 mm |
| height | 32 mm |
