Design | |
product type | IP-Telefon |
Hearing type | Kabelgebundenes Mobilteil |
Product color | Schwarz |
Eigenschaft | Power over Ethernet (PoE) |
Assembly | Tisch/Wand |
phone properties | |
line count | 6 Zeilen |
caller lists | 1000 |
phone book capacity | 1000 Eintragungen |
screen | |
Display | LCD |
screen size | 7,11 cm (2.8") |
Display resolution | 320 x 240 Pixel |
Audio | |
microphone frequency | 0 - 70 Hz |
voice codec | AGC, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, G.729B, G.729ab, PLC, VAD, iLBC |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Bluetooth-Version | 4.2 |
Supported network protocols | SIP2.0 over UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, CDP, LLDP, PPPoE, 802.1x, OpenVPN, SNTP, FTP/TFTP |
Supported security algorithms | EAP, WPA, WPA2-PSK |
connections and interfaces | |
Number of USB 2.0 ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Number of RJ9 ports | 2 |
energy | |
power supply output voltage | 5 V |
AC adapter output current | 2 A |
Power consumption (standard operation) | 4,36 W |
Power Consumption (Power over Ethernet (PoE)) | 6,3 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Operating relative humidity | 10 - 95% |
weight and dimensions | |
broad | 203,8 mm |
depth | 170,8 mm |
height | 166,7 mm |
