Design | |
product type | IP-Telefon |
Hearing type | Kabelgebundenes Mobilteil |
Product color | Schwarz |
Services | |
Dual-Tone-Multifrequenz-Modi (DTMF) | Im Band, Außerhalb des Bandes, SIP-Info |
phone properties | |
line count | 20 Zeilen |
Eigenschaft | Power over Ethernet (PoE) |
caller lists | 1000 |
phone book capacity | 2000 Eintragungen |
management functions | |
volume control | Tasten |
Keyboard Number of keys | 26 |
number of function keys | 5 |
screen | |
Display | LED |
screen size | 17,8 cm (7") |
Display resolution | 840 x 480 Pixel |
Type of touch screen | Kapazitiv |
Audio | |
voice codec | AMR, AMR-WB, G.711a, G.711u, G.722, G.723.1, G.726-32, G.729ab, OPUS, iLBC |
Video | |
video resolution | 320 x 240,640 x 480 Pixel |
Video-Codec | H.264 |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Supported network protocols | SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, IPv6, LLDP, PPPoE, 802.1x, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069 |
connections and interfaces | |
Number of USB 2.0 ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Number of RJ9 ports | 2 |
energy | |
Power consumption (PowerSave) | 8 W |
Power Consumption (Power over Ethernet (PoE)) | 9 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Operating relative humidity | 10 - 95% |
weight and dimensions | |
broad | 268 mm |
depth | 185 mm |
height | 189 mm |
scope of delivery | |
Number of handles included | 1 Stück(e) |
Supplied cables | LAN (RJ-45) |
