Certification | FCC, UL |
Built-in speaker(s) | Yes |
Connectivity Technology | Wired |
Maximum number of cameras supported | 1 |
Colour | Yes |
Sustainability certificates | CE |
Two-way talk | Yes |
I code | IK07 |
Product colour | Silver |
Housing material | Aluminium, Plastic |
Placement supported | Vertical |
LED indicators | Yes |
International Protection (IP) code | IP65 |
Control Type | Buttons |
Power supply voltage | 48 V |
Power source type | DC, PoE |
Power consumption (typical) | 12 W |
AC adapter output current | 1 A |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -30 - 60 °C |
Weight | 350 g |
Height | 130 mm |
Width | 96 mm |
Depth | 28.5 mm |
Ethernet LAN data rates | 10 |
Power Over Ethernet (PoE) | Yes |
Supported network protocols | SIP; P2P; IPv4; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP |
Ethernet LAN (RJ-45) ports | 1 |
Wide Dynamic Range (WDR) | 120 dB |
Video formats supported | H.265 |
Operating system installed | Embedded LINUX |
Maximum Video Resolution | 1280 x 720 pixels |
Focal length range | 1.9 mm |
Viewing angle, horizontal | 168.6° |
Megapixel (approx.) | 2 MP |
Lens viewing angle, diagonal | 176.7° |
Sensor type | CMOS |
Viewing angle, vertical | 87.1° |
Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
Maximum Frame Rate | 30 fps |
Lens type | Wide fish-eye lens |
