Technical details | |
transmission technology | Kabelgebunden |
Eigenschaft | Innengerät inklusive |
Maximum number of supported cameras | 1 |
number of buttons | 1 Tasten |
Country of origin | Deutschland |
Konformitätsbescheinigungen | REACH, RoHS |
Camera | |
Supported video modes | 720p |
Objektivtyp | Ultra-Weitwinkel |
angle of view, horizontal | 140° |
angle of view, vertical | 100° |
Abstand Bewegungssensor | 10 m |
Bewegungssensor-Erfassungswinkel | 180° |
night vision | |
LED Type | IR |
Number of illumination LEDs | 12 |
Audio | |
number of speakers | 1 |
Design | |
Product color | Edelstahl |
International degree of protection (IP code) | IP65 |
IK-Kodex | IK08 |
housing material | Edelstahl |
steering | Tasten |
network | |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
Number of Ethernet LAN ports (RJ-45) | 1 |
wiring technology | 10/100Base-T(X) |
Supported network protocols | HTTP, HTTPS, SSL/TLS, Bonjour, DNS, RTSP, RTP, TCP, UDP, RTCP, ICMP, DHCP, ARP, SIP, DTMF (RTP [RFC-2833], SIP INFO [RFC-2976]), STM |
mesh standard | IEEE 802.3af |
operating conditions | |
operating temperatur | -25 - 55 °C |
Operating relative humidity | 10 - 85% |
weight and dimensions | |
broad | 131 mm |
depth | 48,8 mm |
height | 253 mm |
Weight | 767 g |
