To press | |
Maximum resolution | 203 x 203 DPI |
Print speed (metric) | 250 mm/sek |
pitch | 22,6 Zeichen pro Zoll |
Zeichen | Text, Grafik, Barcode |
Character Map | ANK |
printing technology | |
Type | POS-Drucker |
paper handling | |
Maximum roll diameter | 8,3 cm |
Supported paper width | 80 mm |
connections and interfaces | |
Eigenschaft | AC-Netzadapter |
Number of USB 2.0 ports | 1 |
USB connector type | USB Typ-B |
Serial interface | RS-232 |
transmission technology | Kabelgebunden |
Number of serial ports | 1 |
standard interfaces | RS-232, USB 2.0 |
features | |
Sound pressure level (pressure) | 55 dB |
Mean Time Between Failures (MTBF) | 360000 h |
Car cutter durability | 1,5 Millionen Schnitte |
Lebensdauer des Druckkopfes | 150 km |
Country of origin | Philippinen |
Montageposition | Horizontal/Vertikal |
Details der eingebauten Sensoren | Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor |
safety | UL, CSA, TÜV |
certification | FCC-Class A, CE, EN55022-Class A |
Design | |
Product color | Schwarz |
energy | |
energy source | AC |
AC input voltage | 24 V |
power consumption | 1800 mA |
Power consumption (standby) | 100 mA |
operating conditions | |
operating temperatur | 5 - 45 °C |
Storage temperature range | -10 - 50 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 10 - 90% |
weight and dimensions | |
broad | 140 mm |
depth | 199 mm |
height | 146 mm |
Weight | 1,7 kg |
Supplied cables | AC |
quantity per pack | 1 Stück(e) |
package weight | 2,62 kg |
scope of delivery | |
Teilenkapazität | 48/64 |
logistic data | |
Goods tariff number (HS) | 84433210 |
Number of products per shipping carton | 4 Stück(e) |
Shipping box width | 400 mm |
Shipping carton length | 490 mm |
Shipping carton height | 295 mm |
products per pallet | 112 Stück(e) |
products per pallet layer | 16 Stück(e) |
Products per pallet layer (UK) | 24 Stück(e) |
Technical details | |
Lebenszeit | 15000000 lines |
Other functions | |
buffer size | 4 KB |
Mittelzyklen zwischen Fehler (MCBF) | 60000000 |
Lebensdauer Druckkopf | 150.000.000 Impulse |
Print head life | 150 Millionen Zeichen |
