| To press | |
| Maximum resolution | 203 x 203 DPI |
| Print speed (metric) | 250 mm/sek |
| pitch | 22,6 Zeichen pro Zoll |
| Zeichen | Text, Grafik, Barcode |
| Character Map | ANK |
| printing technology | |
| Type | POS-Drucker |
| paper handling | |
| Maximum roll diameter | 8,3 cm |
| Supported paper width | 80 mm |
| connections and interfaces | |
| Eigenschaft | AC-Netzadapter |
| Number of USB 2.0 ports | 1 |
| USB connector type | USB Typ-B |
| Serial interface | RS-232 |
| transmission technology | Kabelgebunden |
| Number of serial ports | 1 |
| standard interfaces | RS-232, USB 2.0 |
| features | |
| Sound pressure level (pressure) | 55 dB |
| Mean Time Between Failures (MTBF) | 360000 h |
| Car cutter durability | 1,5 Millionen Schnitte |
| Lebensdauer des Druckkopfes | 150 km |
| Country of origin | Philippinen |
| Montageposition | Horizontal/Vertikal |
| Details der eingebauten Sensoren | Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor |
| safety | UL, CSA, TÜV |
| certification | FCC-Class A, CE, EN55022-Class A |
| Design | |
| Product color | Schwarz |
| energy | |
| energy source | AC |
| AC input voltage | 24 V |
| power consumption | 1800 mA |
| Power consumption (standby) | 100 mA |
| operating conditions | |
| operating temperatur | 5 - 45 °C |
| Storage temperature range | -10 - 50 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 10 - 90% |
| weight and dimensions | |
| broad | 140 mm |
| depth | 199 mm |
| height | 146 mm |
| Weight | 1,7 kg |
| Supplied cables | AC |
| quantity per pack | 1 Stück(e) |
| package weight | 2,62 kg |
| scope of delivery | |
| Teilenkapazität | 48/64 |
| logistic data | |
| Palettengewicht (UK) | 0 g |
| Goods tariff number (HS) | 84433210 |
| Number of products per shipping carton | 4 Stück(e) |
| Shipping box width | 400 mm |
| Shipping carton length | 490 mm |
| Shipping carton height | 295 mm |
| Shipping carton weight | 0 g |
| products per pallet | 112 Stück(e) |
| products per pallet layer | 16 Stück(e) |
| Pallet weight (gross) | 0 g |
| Products per pallet layer (UK) | 24 Stück(e) |
| Technical details | |
| Lebenszeit | 15000000 lines |
| Other functions | |
| buffer size | 4 KB |
| Mittelzyklen zwischen Fehler (MCBF) | 60000000 |
| Lebensdauer Druckkopf | 150.000.000 Impulse |
| Print head life | 150 Millionen Zeichen |
