Scan | |
Type | Tragbares Barcodelesegerät |
Scanner Type | 1D/2D |
Linear (1D) barcodes supported | China Post, Code 128, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, UPC-A, UPC-E |
2D (Matrix & Stacked) barcodes supported | Aztec Code, Datenmatrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code |
Optical sensor resolution (W x H) | 1280 x 800 Pixel |
working distance | 20 cm |
Light Levels (direct sunlight) | 0 - 100000 Lux |
wavelength | 630 nm |
tilt reading angle | 0 - 360° |
slope reading angle | -52 - 52° |
Gierlese shop | -52 - 52° |
connections and interfaces | |
transmission technology | Kabelgebunden |
standard interfaces | USB |
Services | |
International degree of protection (IP code) | IP65, IP67 |
protective function | Schmutzabweisend, Tropfsicher, Staubresistent, Schutz vor elektrostatischer Entladung (ESD), Wasserfest |
Eigenschaft | Vibrationsfunktion |
print contrast | 15% |
Product color | Schwarz, Gelb |
energy | |
energy source | USB |
input voltage | 5 - 30 V |
power consumption | 280 mA |
weight and dimensions | |
broad | 79 mm |
depth | 140 mm |
height | 190 mm |
Weight | 318 g |
Supplied cables | USB |
operating conditions | |
operating temperatur | -20 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 0 - 95% |
Technical details | |
Konformitätsbescheinigungen | REACH, RoHS |
logistic data | |
Goods tariff number (HS) | 84716070 |
