Scan | |
Maximum scan dimension | 216 x 3048 mm |
Optical scan resolution | 600 x 600 DPI |
Eigenschaft | Netzwerkfähig |
Output color depth | 24 Bit |
Output grayscale depth | 8 Bit |
Output monochrome depth | 1 Bit |
ADF scan speed (b/w, A4) | 25 Seiten pro Minute |
Duplex ADF scan speed (b/w, A4) | 50 ipm |
Black and white scan color mode | Graustufen, Monochrom |
Design | |
Scanner Type | ADF-Scanner |
Product color | Schwarz |
Display | LCD |
screen size | 21,3 cm (8.4") |
Display resolution | 1024 x 768 Pixel |
Services | |
Sensor-Typ | CIS |
light source | RGB-LED |
Scanner File Formats | JPG, PDF, TIFF |
Daily duty cycle (max) | 400 Seiten |
Scan to | E-Mail, E-Mail-Server, Faxen, Datei, FTP |
input capacitance | |
Automatic Document Feeder (ADF) capacity | 50 Blätter |
paper handling | |
Supported scan media types | Visitenkarte, Normales Papier, Plastik-Karte, Post Card(JPN), Dickes Papier, Dünnes Papier |
Maximum paper size of ISO A series | A4 |
ISO-A-Formate (A0...A9) | A4, A5, A6, A8 |
ISO-B-Format | B5, B6 |
Automatic Document Feeder (ADF) Media Weight | 40 - 209 g/m² |
Maximum Scan Size (Auto Document Loader) | 216 x 355,6 mm |
Scanformat ADF (minimum) | 50,8 x 50,8 mm |
connections and interfaces | |
USB-Version | 2.0 |
Buchsenstecker-Typ | C7 |
standard interfaces | Ethernet, USB 1.1, USB 2.0 |
network | |
Supported network protocols | TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP |
energy | |
power supply type | AC |
Power consumption (standard operation) | 38 W |
Power consumption (standby) | 1 W |
Power consumption (PowerSave) | 2 W |
AC input frequency | 50 - 60 Hz |
input voltage | 100-240 V |
weight and dimensions | |
broad | 300 mm |
depth | 232 mm |
height | 172 mm |
Weight | 6 kg |
quantity per pack | 1 Stück(e) |
package weight | 8 kg |
scope of delivery | |
Supplied cables | AC |
Included software | Scanner Central Admin Server |
sustainability | |
sustainability certificates | ENERGY STAR |
system requirement | |
operating conditions | |
operating temperatur | 5 - 35 °C |
Operating relative humidity | 20 - 80% |
Other functions | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Konformitätsbescheinigungen | RoHS |
logistic data | |
Country of origin | China |
Pallet length (gross) | 101,6 cm |
Pallet width (gross) | 121,9 cm |
Goods tariff number (HS) | 8471607000 |
Gewicht der Papierverpackung | 2,4 kg |
Gewicht der Metallverpackung | 0 g |
Gewicht der Holzverpackung | 0 g |
Gewicht der Plastikverpackung | 15 g |
Gewicht der Kartonverpackung | 1,2 kg |
Folienverpackungsgewicht | 15 g |
Gewicht der Polystyrolverpackung (EPS/EPP) | 200 g |
Glass packaging weight | 0 g |
