Linear (1D) barcodes supported | Code 3 of 9 |
PC Connection | USB 3.2 Gen 1 (3.1 Gen 1) |
Power | 36 W |
Sustainability certificates | ENERGY STAR |
Relative humidity | 15 - 80% |
Maximum paper size | 216 x 3000 mm |
Scan Technology | Dual CIS |
Scanner type | ADF scanner |
Display diagonal | 3.81 cm (1.5") |
Product colour | White |
Touchscreen | No |
Display | LCD |
Built-in Display | Yes |
AC input frequency | 50 - 60 Hz |
Input voltage | 100-240 V |
Power consumption (off) | 0.5 W |
Power supply type | AC |
Power consumption (typical) | 36 W |
Power consumption (PowerSave) | 3 W |
Power consumption (standby) | 3 W |
Power supply | 36 W |
Operating relative humidity (H-H) | 15 - 80% |
Operating temperature (T-T) | 50 - 95 °F |
Depth | 204 mm |
Width | 312 mm |
Weight | 3.3 kg |
Height | 182.5 mm |
Windows operating systems supported | Windows 8.1 |
Minimum RAM | 4000 MB |
Minimum processor | INTEL CORE i3 - 4150 processor |
Scan to | WIA |
Built-in processor | Yes |
Processor frequency | 1500 MHz |
Scan file formats | XLS |
Sensor type | Dual CIS |
Button functions | Cancel, down, Off, On, Scan, Up |
Barcode Reader | Yes |
Scan drivers | WIA |
Daily duty cycle (max) | 7000 pages |
Light source | RGB LED |
Bundled software | WINDOWS Bundled software: TWAIN, ISIS, WIA Drivers; Alaris Capture Pro Limited, Smart Touch, LINUX drivers available from www.kodak.com/go/scanonlinux (September Availability) KOFAX certified. (Future Availability) |
Drivers included | Yes |
CABLES INCLUDED | AC, USB |
Stacker | Yes |
ADF paper chute | Yes |
Standard interfaces | USB 3.2 Gen 1 (3.1 Gen 1) |
USB version | 3.2 Gen 2 (3.1 Gen 2) |
USB Port | Yes |
Downloadable software | Capture Pro Limited Edition, Smart Touch |
Harmonized System (HS) code | 84716070 |
Standard input capacity | 80 sheets |
Auto document feeder (ADF) input capacity | 80 sheets |
Auto Document Feeder (ADF) media weight | 27 - 433 g/m² |
Legal | Yes |
Scanning media types supported | Plastic Card |
Maximum scan length | 3 m |
Maximum scan width | 21.6 cm |
ISO A-series sizes (A0...A9) | A4 |
Maximum ISO A-series paper size | A4 |
Maximum scan area (ADF) | 216 x 356 mm |
Minimum scan area (ADF) | 52 x 52 mm |
Multi feed detection | Yes |
Maximum scan size | 216 x 3000 mm |
Duplex ADF scan speed (b/w, A4) | 140 ipm |
Black/white scanning colour modes | Grayscale |
Output greyscale depth | 8 bit |
Greyscale levels | 256 |
Optical scanning resolution | 600 x 600 DPI |
ADF scan speed (b/w, A4) | 70 ppm |
Colour scanning | Yes |
ADF scan speed (colour, A4) | 70 ppm |
Input colour depth | 30 bit |
Duplex ADF scan speed (colour, A4) | 140 ipm |
ADF scan speed (greyscale, A4) | 70 ppm |
Output colour depth | 24 bit |
Film scanning | No |
Duplex scanning | Yes |
Selectable background colour | No |
