Battery Technology | Lithium Polymer (LiPo) |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 5 - 85% |
Weight | 224 g |
Certification | EMC FCC Part 15 Class B, ICES 003 Class B,
IEC 60601-1-2 RoHS 2002/95/EEC |
Product colour | Black |
LED indicators | Charging |
International Protection (IP) code | IP54 |
Housing material | Plastic |
CABLES INCLUDED | RS-232 |
Bluetooth | Yes |
Standard interfaces | RS-232, RS-485, USB, Keyboard wedge |
Cable length | 1.8 m |
Light source | LED |
Dimensions (WxDxH) | 70 x 186 x 98 mm |
Shockproof | No |
Safety | C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950- 1 LED Class 1 |
Harmonized System (HS) code | 84716070 |
Decoding standards | UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN
8, EAN-13/JAN 13, Bookland EAN, Bookland
ISBN Format, UCC Coupon Extended Code,
ISSN EAN
Code 128 Including GS1-128, ISBT
128, ISBT Concatenation, Code 39 including
Trioptic Code 39, Convert Code 39 to Code
32 (Italian Pharmacy Code), Code 39 Full
ASCII Conversion Code 93 Code 11 Matrix
2 of 5 Interleaved 2 of 5 (ITF) Discrete 2
of 5 (DTF) Codabar (NW - 7) MSI Chinese
2 of 5 IATA
Inverse 1D (except all GS1
DataBars) GS1 DataBar including GS1
DataBar-14, GS1 DataBar Limited, GS1 |
Tilt angle range | 0 - 35° |
Light levels (direct sunlight) | 0 - 108 lx |
Maximum scan width | 10 cm |
Tilt reading angle | 0 - 45° |
Maximum range | 6 m |
Wavelength | 612 nm |
Pitch reading angle | 0 - 65° |
Yaw reading angle | 0 - 65° |
Read rate (max) | 547 reads/s |
