Scan | |
Maximum scan dimension | 216 x 5588 mm |
Optical scan resolution | 600 x 600 DPI |
Eigenschaft | Treiber enthalten |
Output color depth | 24 Bit |
Output grayscale depth | 8 Bit |
Output monochrome depth | 1 Bit |
Duplex ADF scan speed (color, A4) | 120 ipm |
Black and white scan color mode | Graustufen, Monochrom |
Design | |
Scanner Type | ADF-Scanner |
Product color | Grau, Weiß |
Display | TFT |
screen size | 10,9 cm (4.3") |
Services | |
Sensor-Typ | Dual CCD |
light source | Weiße LED (2x) |
Daily duty cycle (max) | 4000 Seiten |
scan driver | ScanSnap, TWAIN, WIA |
input capacitance | |
Automatic Document Feeder (ADF) capacity | 80 Blätter |
paper handling | |
Supported scan media types | Normales Papier, Plastik-Karte |
Maximum paper size of ISO A series | A4 |
Automatic Document Feeder (ADF) Media Weight | 27 - 413 g/m² |
Maximum scanweite | 21,6 cm |
Maximum scan length | 5,59 m |
Scanformat ADF (minimum) | 50,8 x 54 mm |
connections and interfaces | |
USB-Version | 3.2 Gen 2 (3.1 Gen 2) |
Buchsenstecker-Typ | C5 |
standard interfaces | Ethernet, USB 1.1, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN |
network | |
WLAN-Standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Supported network protocols | IPv4(15), TCP, UDP, ICMP, DHCP, HTTP/HTTPS, DNS |
energy | |
power supply type | AC |
Power consumption (standard operation) | 42 W |
power consumption (off) | 0,35 W |
Power consumption (PowerSave) | 2,4 W |
input voltage | 100 - 240 V |
weight and dimensions | |
broad | 300 mm |
depth | 202 mm |
height | 170 mm |
Weight | 49 kg |
quantity per pack | 1 Stück(e) |
package weight | 7,2 kg |
scope of delivery | |
Supplied cables | AC, USB |
sustainability | |
sustainability certificates | ENERGY STAR |
system requirement | |
Minimum disk space required | 120000 MB |
Minimum processor | 3.5 GHz |
Supported server operating systems | Windows Server 2008, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016 x64 |
operating conditions | |
operating temperatur | 5 - 35 °C |
Operating relative humidity | 20 - 80% |
temperature operating environment | 41 - 95 °F |
Other functions | |
Konformitätsbescheinigungen | RoHS |
background colors | Schwarz, Weiß |
logistic data | |
Country of origin | Indonesien |
Pallet length (gross) | 121,9 cm |
Pallet width (gross) | 101,6 cm |
Goods tariff number (HS) | 8471607000 |
Gewicht der Papierverpackung | 2,4 kg |
Gewicht der Metallverpackung | 0 g |
Gewicht der Holzverpackung | 0 g |
Gewicht der Plastikverpackung | 15 g |
Gewicht der Kartonverpackung | 1,2 kg |
Folienverpackungsgewicht | 15 g |
Gewicht der Polystyrolverpackung (EPS/EPP) | 200 g |
Glass packaging weight | 0 g |
