| Scan | |
| Maximum scan dimension | 216 x 360 mm |
| Optical scan resolution | 600 x 600 DPI |
| Eigenschaft | Treiber enthalten |
| Scan speed (b/w, A4) | 5 Sekunde/Seite |
| Black and white scan color mode | Graustufen, Monochrom |
| Design | |
| Scanner Type | CDF + Bogenscanner |
| Product color | Schwarz |
| Services | |
| Sensor-Typ | CIS |
| light source | RGB-LED |
| Built-in processor | GI |
| paper handling | |
| Supported scan media types | Visitenkarte, Fotopapier, Normales Papier, Post Card(JPN) |
| Maximum paper size of ISO A series | A4 |
| ISO-A-Formate (A0...A9) | A4, A5, A6 |
| ISO-B-Format | B5, B6 |
| connections and interfaces | |
| USB-Version | 2.0 |
| standard interfaces | USB 1.1, USB 2.0, Wireless LAN |
| network | |
| WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| energy | |
| power supply type | Wechselstrom/Batterie |
| Power consumption (standard operation) | 4,7 W |
| Power consumption (standby) | 0,5 W |
| power consumption (off) | 0,5 W |
| Power consumption (PowerSave) | 2,2 W |
| input voltage | 5 V |
| Rechargeable battery technology | Lithium-Ion (Li-Ion) |
| amperage | 0,5 A |
| battery capacity | 720 mAh |
| weight and dimensions | |
| broad | 273 mm |
| depth | 47,5 mm |
| height | 36 mm |
| Weight | 400 g |
| quantity per pack | 1 Stück(e) |
| package weight | 400 g |
| scope of delivery | |
| Supplied cables | USB |
| Included software | ScanSnap Manager 6.3ScanSnap OrganizerCardMinder 5.2ABBYY FineReader for ScanSnap 5.0Scan to Microsoft SharePoint |
| sustainability | |
| sustainability certificates | ENERGY STAR |
| system requirement | |
| Supports Mac operating systems | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| operating conditions | |
| operating temperatur | 5 - 35 °C |
| Operating relative humidity | 20 - 80% |
| Other functions | |
| Mindest Scan-Format | 25.4 x 25.4mm |
| Scan Media Weight | 52 - 209 g/m² |
| Konformitätsbescheinigungen | RoHS |
| logistic data | |
| Country of origin | China |
| Pallet length (gross) | 101,6 cm |
| Pallet width (gross) | 121,9 cm |
| Goods tariff number (HS) | 8471607000 |
| Gewicht der Papierverpackung | 2,4 kg |
| Gewicht der Metallverpackung | 0 g |
| Gewicht der Holzverpackung | 0 g |
| Gewicht der Plastikverpackung | 15 g |
| Gewicht der Kartonverpackung | 1,2 kg |
| Folienverpackungsgewicht | 15 g |
| Gewicht der Polystyrolverpackung (EPS/EPP) | 200 g |
| Glass packaging weight | 0 g |
