Type Fixed/Outdoor | Pixel Resolution 4 Mega Pixel | Focal Length 2.8 mm | IR Illumination | Sensor size 1/2.9 ” CMOS | Microphone Built-in | Lens Mount M12 | Min. Illumination 0.0008 Lux | Effective pixels Auto/Manual 1/3 s–1/100,000 s | 1xMicroSD Card Slot | 1xRJ45 | Supports card capacities up to 256GB | Power options PoE/12V | Power supply requirements PoE / 12VDC | Environment Outdoor | Operating temperature range -40°C~+60°C | Dimensions 166.2 mm × 70 mm × 70 mm
| Description | - 1/2.9 ” CMOS; 2688x1520 @ 20FPS
- Minimum illumination: 0.008 lux @ F1.6 (Color, 30 IRE); 0.0008 lux @ F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
- True Day/Night (ICR), BLC/ HLC/ True WDR(120dB) / 3D DNR
- 2.8 mm fixed lens (95°)
- Up to 30 meters IR Illumination, Smart IR
- ONVIF (Profile S/Profile T); CGI; P2P; Milestone
- SD Card slot 256 GB max, Built-in MIC
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Bullet design, Metal case, IP67, -40°C~+60°C, PoE / 12VDC power. 4.2 W max
- Free IP monitoring software available
|
| Страница производителя | www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-Series/2-Series/4MP/IPC-HFW2441S-S |
| Модель | DH-IPC-HFW2441S-S-0280B |
| Дизайн камеры | Bullet |
| Тип IP-камеры | Fixed/Outdoor |
| Эффективное количество пикселов | 4 Mega Pixel |
| Фокусное расстояние объектива | 2.8 mm |
| ИК-подсветка | Yes |
| Размер сенсора | 1/2.9 ” CMOS |
| Микрофон | Built-in |
| Крепление объектива | M12 |
| Светочувствительность | 0.0008 Lux |
| Кол-во эффективных пикселей | Auto/Manual 1/3 s–1/100,000 s |
| MicroSD слот | 1 |
| RJ45 | 1 |
| Поддерживает емкость карт до | 256GB |
| Параметры питания | 12V/PoE |
| Требование к блоку/адаптеру питания | PoE / 12VDC |
| Энергопотребление | 4.2 Watts |
| Окружающая обстановка | Outdoor |
| Диапазон рабчоих температур | -40°C~+60°C |
| Размер (физические параметры) | 166.2 mm × 70 mm × 70 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.00231 cubm |
| Product Net Weight | 0.48 kg |
| Unit Calculated Weight | 0.589 kg |
| CnCode | 85258900 |
| Ширина коробки блока | 0.1 |
| Длина коробки блока | 0.21 |
| Высота коробки блока | 0.11 |
| Полное подробное описание | Type Fixed/Outdoor|Pixel Resolution 4 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/2.9 ” CMOS|Microphone Built-in|Lens Mount M12|Min. Illumination 0.0008 Lux|Effective pixels Auto/Manual 1/3 s–1/100,000 s|1xMicroSD Card Slot|1xRJ45|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements PoE / 12VDC|Environment Outdoor|Operating temperature range -40°C~+60°C|Dimensions 166.2 mm × 70 mm × 70 mm |
| Код категории | FNC |
