Type HDTV/Megapixel/Outdoor | Pixel Resolution 5 Mega Pixel | Focal Length 2.7 mm–13.5 mm | IR Illumination | Sensor size 1/2.7" | Microphone Built-in | Min. Illumination 0.0005 Lux | Effective pixels 2960 (H) × 1668 (V) | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | 1xRJ45 | Supports card capacities up to 256GB | Power options PoE/12V | Power supply requirements Basic: 5.7 W (12 VDC); 6.4 W (PoE) Max. (WDR + IR intensity + Intelligence): 8.9 W (12 VDC); 10.2 W (PoE) | Environment Outdoor | Colour White | Dimensions 108.3 mm × Φ122 mm
| Description | 5MP IR Vari-focal Eyeball WizSense Network Camera
> 5-MP 1/2.7" CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 5 MP (2960 × 1668) @20 fps and supports 4MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 40 m.
> ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD 4.0, AI SSA.
|
| Страница производителя | www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-Series/3-Series/5MP/IPC-HDW3541T-ZS-S2=S2 |
| Модель | IPC-HDW3541T-ZS-27135-S2 |
| Дизайн камеры | Eyeball |
| Тип IP-камеры | HDTV/Megapixel/Outdoor |
| Эффективное количество пикселов | 5 Mega Pixel |
| Фокусное расстояние объектива | 2.7 mm–13.5 mm |
| ИК-подсветка | Yes |
| Размер сенсора | 1/2.7" |
| Микрофон | Built-in |
| Светочувствительность | 0.0005 Lux |
| Кол-во эффективных пикселей | 2960 (H) × 1668 (V) |
| Выдержка (с электронным управлением) | Auto/Manual 1/3 s–1/100,000 s |
| RJ45 | 1 |
| Поддерживает емкость карт до | 256GB |
| Параметры питания | 12V/PoE |
| Требование к блоку/адаптеру питания | Basic: 5.7 W (12 VDC); 6.4 W (PoE) Max. (WDR + IR intensity + Intelligence): 8.9 W (12 VDC); 10.2 W (PoE) |
| Энергопотребление | 6.4 Watts |
| Окружающая обстановка | Outdoor |
| Цвет | White |
| Размер (физические параметры) | 108.3 mm × Φ122 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.003123 cubm |
| Product Net Weight | 0.715 kg |
| Unit Calculated Weight | 0.87 kg |
| CnCode | 85258900 |
| Ширина коробки блока | 0.155 |
| Длина коробки блока | 0.155 |
| Высота коробки блока | 0.13 |
| Полное подробное описание | Type HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 2.7 mm–13.5 mm|IR Illumination|Sensor size 1/2.7"|Microphone Built-in|Min. Illumination 0.0005 Lux|Effective pixels 2960 (H) × 1668 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xRJ45|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements Basic: 5.7 W (12 VDC); 6.4 W (PoE) Max. (WDR + IR intensity + Intelligence): 8.9 W (12 VDC); 10.2 W (PoE)|Environment Outdoor|Colour White|Dimensions 108.3 mm × Φ122 mm |
| Код категории | FNC |
