Type HDTV/Megapixel/Outdoor | Resolution 8 Mega Pixel | Focal Length 2.8mm | Sensor size 1/2.7" | Microphone Built-in | Lens Mount M12 | Min. Illumination 0.0008 Lux | Effective pixels 3840 (H) × 2160 (V) | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | Power options PoE/12V | Power supply requirements 12 VDC/PoE (802.3af) | Environment Outdoor | Operating temperature range –40 °C to +55 °C | Colour White | Dimensions 85.6 mm × Φ94.0 mm
| Description | > 8-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 × 1520@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in multi-core light, the max. IR distance is 30 m and the max. warm light distance is 30 m.
> Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Built in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> Supports human detection.
> Focal Length 2.8mm. Field of View 110°
|
| Страница производителя | material.dahuasecurity.com/uploads/cpq/prm-os-srv-res/smart/datasheetzipfiles/IPC-HDW1839T-A-IL_S6_datasheet_20240415.pdf |
| Код категории | FNC |
| RJ45 | 1 |
| Дизайн камеры | Eyeball |
| Тип IP-камеры | HDTV/Megapixel/Outdoor |
| Эффективное количество пикселов | 8 Mega Pixel |
| Фокусное расстояние объектива | 2.8mm |
| Размер сенсора | 1/2.7" |
| Микрофон | Built-in |
| Крепление объектива | M12 |
| Светочувствительность | 0.0008 Lux |
| Кол-во эффективных пикселей | 3840 (H) × 2160 (V) |
| Выдержка (с электронным управлением) | Auto/Manual 1/3 s–1/100,000 s |
| Параметры питания | 12V/PoE |
| Требование к блоку/адаптеру питания | 12 VDC/PoE (802.3af) |
| Энергопотребление | 5.8 Watts |
| Окружающая обстановка | Outdoor |
| Диапазон рабчоих температур | –40 °C to +55 °C |
| Цвет | Белый |
| Размер (физические параметры) | 85.6 mm × Φ94.0 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.004913 cubm |
| Product Net Weight | 0.35 kg |
| Unit Calculated Weight | 0.46 kg |
