Type Fixed Dome/HDTV/Megapixel/Outdoor | Pixel Resolution 8 Mega Pixel | Focal Length 2.7 mm–13.5 mm | IR Illumination | Sensor size 1/2.7" | Microphone Built-in | Lens Mount M14 | Min. Illumination 0.0008 Lux | Effective pixels 3840 (H) × 2160 (V) | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | 1xAudio-In | 1xAudio-Out | 1xRJ45 | 1xAlarm In | 1xAlarm Out | Supports card capacities up to 256GB | Power options PoE/12V | Power supply requirements 12 VDC/PoE (802.3af) | Environment Outdoor | Operating temperature range –30 °C to +60 °C | Colour Black | Dimensions 93.4 mm × Φ122 mm
| Description | 8MP IR Vari-focal Dome WizSense Network Camera
> 8-MP 1/2.7" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 ×1520 (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); supports max. 256 G Micro SD card; built in MIC.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 protection.
> SMD Plus.
|
| Страница производителя | www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/2-Series/8MP/IPC-HDBW2841R-ZAS |
| Модель | IPC-HDBW2841R-ZAS-27135-B |
| Дизайн камеры | Dome |
| Тип IP-камеры | Fixed Dome/HDTV/Megapixel/Outdoor |
| Эффективное количество пикселов | 8 Mega Pixel |
| Фокусное расстояние объектива | 2.7 mm–13.5 mm |
| ИК-подсветка | Yes |
| Размер сенсора | 1/2.7" |
| Микрофон | Built-in |
| Крепление объектива | M14 |
| Светочувствительность | 0.0008 Lux |
| Кол-во эффективных пикселей | 3840 (H) × 2160 (V) |
| Выдержка (с электронным управлением) | Auto/Manual 1/3 s–1/100,000 s |
| Входные порты | 1 |
| Выходные порты | 1 |
| Аудио-вход | 1 |
| Аудио-выход | 1 |
| RJ45 | 1 |
| Поддерживает емкость карт до | 256GB |
| Параметры питания | 12V/PoE |
| Требование к блоку/адаптеру питания | 12 VDC/PoE (802.3af) |
| Энергопотребление | 3.4 Watts |
| Окружающая обстановка | Outdoor |
| Диапазон рабчоих температур | –30 °C to +60 °C |
| Цвет | Black |
| Размер (физические параметры) | 93.4 mm × Φ122 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.003327 cubm |
| Product Net Weight | 0.51 kg |
| Unit Calculated Weight | 0.7 kg |
| Ширина коробки блока | 0.156 |
| Длина коробки блока | 0.158 |
| Высота коробки блока | 0.135 |
| Полное подробное описание | Type Fixed Dome/HDTV/Megapixel/Outdoor|Pixel Resolution 8 Mega Pixel|Focal Length 2.7 mm–13.5 mm|IR Illumination|Sensor size 1/2.7"|Microphone Built-in|Lens Mount M14|Min. Illumination 0.0008 Lux|Effective pixels 3840 (H) × 2160 (V)|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements 12 VDC/PoE (802.3af)|Environment Outdoor|Operating temperature range –30 °C to +60 °C|Colour Black|Dimensions 93.4 mm × Φ122 mm |
| Код категории | FNC |
