Type HDTV/Megapixel/Outdoor/PTZ | Pixel Resolution 3 Mega Pixel | Focal Length 2.8 mm; 6 mm | IR Illumination | Sensor size 1/2.8" CMOS | Microphone Built-in | 1xMicroSD Card Slot | 1xRJ45 | Supports card capacities up to 256GB | Power options 12V | Power supply requirements Basic: 2.3 W/ Max.: 10 W (pulling stream+ IR + siren and light active deterrence) | Operating temperature range –20 °C to +50 °C | Included Accessories power supply | Dimensions 159.4 mm × 119.1 mm × 210 mm
| Description | P3D-3F-PV
3+3MP Outdoor Wi-Fi Dual-Lens Pan & Tilt Camera, for outdoor or indoor use.
The Picoo Dual Series, which is under the Dahua Wireless series, consists of cameras equipped with both fixed lens and PT lens. This unique combination allows for simultaneous live monitoring of two areas, providing coverage from multiple angles. Leveraging its dual lenses, the camera performs smart detection using advanced functions like AI human and vehicle detection, effectively minimizing false alarms. Additionally, with the assistance of the PT lens, the camera has the capability to automatically track moving targets. The camera also triggers sound and light alarms upon detecting an intrusion, promptly sending notifications to the mobile client to ensure you remain up to date regardless of your location. These cameras are widely utilized in small-scale scenes such as shops and restaurants.
Field of view: 95°(Fixed) + 53°(PT), IR / white LED illumination distance: up to 50 m, power supply and mounting accessories included |
| Страница производителя | https://www.dahuasecurity.com/products/All-Products/Network-Cameras/Wireless-Series/NEW-Channel/Outdoor-Camera/Picoo-Series/P3D-3F-PV |
| Модель | P3D-3F-PV-0280B/0600B |
| Дизайн камеры | Dome |
| Тип IP-камеры | HDTV/Megapixel/Outdoor/PTZ |
| Эффективное количество пикселов | 3 Mega Pixel |
| Фокусное расстояние объектива | 2.8 mm; 6 mm |
| ИК-подсветка | Yes |
| Размер сенсора | 1/2.8" CMOS |
| Микрофон | Built-in |
| Беспроводные соединения | Bluetooth/WiFi/WLAN |
| MicroSD слот | 1 |
| RJ45 | 1 |
| Поддерживает емкость карт до | 256GB |
| Параметры питания | 12V |
| Требование к блоку/адаптеру питания | Basic: 2.3 W/ Max.: 10 W (pulling stream+ IR + siren and light active deterrence) |
| Энергопотребление | 2.3 Watts |
| Диапазон рабчоих температур | –20 °C to +50 °C |
| Аксессуары идущие в комплекте | power supply |
| Размер (физические параметры) | 159.4 mm × 119.1 mm × 210 mm |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.005744 cubm |
| Product Net Weight | 0.585 kg |
| Unit Calculated Weight | 0.96 kg |
| Ширина коробки блока | 0.135 |
| Длина коробки блока | 0.185 |
| Высота коробки блока | 0.23 |
| Полное подробное описание | Type HDTV/Megapixel/Outdoor/PTZ|Pixel Resolution 3 Mega Pixel|Focal Length 2.8 mm; 6 mm|IR Illumination|Sensor size 1/2.8" CMOS|Microphone Built-in|1xMicroSD Card Slot|1xRJ45|Supports card capacities up to 256GB|Power options 12V|Power supply requirements Basic: 2.3 W/ Max.: 10 W (pulling stream+ IR + siren and light active deterrence)|Operating temperature range –20 °C to +50 °C|Included Accessories power supply|Dimensions 159.4 mm × 119.1 mm × 210 mm |
| Код категории | FNC |
