Channels 16 | Drives/bays 2 | SATA | 1x15pin D-sub | 1xHDMI | 1xAudio-In | 1xAudio-Out | 2xUSB 2.0 | 1xRJ45 | 4xAlarm In | 2xAlarm Out | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375 mm × 284.3 mm × 53 mm | Temp. range –10 °C to +55 °C
Description | - 16 IP channel max, up to 16MP resolution
- Max: 256Mbps recording bandwidth, Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
- VGA/HDMI up to 4K output, decoding up to 2-channel 16 MP @ 30 fps
- 2 SATA III ports, up to 16 TB for a single HDD
- No front panel control, 4/2 alarm I/O, 2 USB, Two-way Talk: 1/1
- Desktop mounted chassis
- AI by NVR: 1-channel face detection and recognition; 2-channel perimeter protection; up to 10 face databases and 20,000 face images; 4-channel SMD Plus.
- AI by Camera: Face detection and recognition, perimeter protection; SMD Plus; people counting; stereo analysis; heat map.Free IP monitoring software available, ONVIF 22.06 (Profile T; Profile S; Profile G); CGI; SDK
- Other brands IP cameras supported
|
Страница производителя | www.dahuasecurity.com/ceen/products/All-Products/Network-Recorders/WizSense-Series/NVR-4-EI-Series/2-HDD/NVR4216-EI |
Модель | NVR4216-EI |
Количество каналов | 16 |
Количество дисков/отсеков | 2 |
САТА | Yes |
15-контактный разъем D-sub | 1 |
Входные порты | 4 |
Выходные порты | 2 |
Аудио-вход | 1 |
Аудио-выход | 1 |
HDMI | 1 |
RJ45 | 1 |
USB 2.0 | 2 |
Требование к блоку/адаптеру питания | 12 VDC, 4 A |
Энергопотребление | 10 Watts |
Размер (физические параметры) | 375 mm × 284.3 mm × 53 mm |
Диапазон рабчоих температур | –10 °C to +55 °C |
Вес | 1.51 kg |
Вес брутто | 2.77 kg |
Ширина коробки блока | 0.14 |
Длина коробки блока | 0.435 |
Высота коробки блока | 0.36 |
Полное подробное описание | Channels 16|Drives/bays 2|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|4xAlarm In|2xAlarm Out|Power supply requirements 12 VDC, 4 A|Power consumption 10 Watts|Dim. 375 mm × 284.3 mm × 53 mm|Temp. range –10 °C to +55 °C |
Код категории | NVR |
