Channels 16 | Drives/bays 2 | Desktop/pedestal | Rack 1U | Integrated LAN Gigabit | 1x15pin D-sub | 1xHDMI | 1xAudio-In | 1xAudio-Out | 1xRS232 | 1xUSB 2.0 | 1xUSB 3.0 | 1xRJ45 | 1xRS-485 | 4xAlarm In | 2xAlarm Out | Power supply requirements 12 VDC, 4 A | Power consumption 10 Watts | Dim. 375.0 × 284.4 x 56.0mm | Temp. range –10 °C to +55 °C
Description | "16 Channels 1U 2HDDs WizSense Network Video Recorder
> Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
> Max. decoding capability: 32 × 1080p@30 fps or 16 × 4MP@30 fps.
> Max. 384 Mbps incoming/recording/outgoing bandwidth.
> Support AcuPick with Max. 16-Channel.
> Support N+M cluster.
> AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus.
> AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
> Security baseline 2.3"
|
Страница производителя | www.dahuasecurity.com/ceen/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/2HDD/NVR5216-EI |
Модель | NVR5216-EI |
Количество каналов | 16 |
Количество дисков/отсеков | 2 |
Десктоп-/башенный тип | Yes |
Стойка 1U | Yes |
Интегрированная сетевая карта | Gigabit |
15-контактный разъем D-sub | 1 |
Входные порты | 4 |
Выходные порты | 2 |
Аудио-вход | 1 |
Аудио-выход | 1 |
HDMI | 1 |
RJ45 | 1 |
RS232 | 1 |
РС-485 | 1 |
USB 2.0 | 1 |
USB 3.0 | 1 |
Требование к блоку/адаптеру питания | 12 VDC, 4 A |
Энергопотребление | 10 Watts |
Размер (физические параметры) | 375.0 × 284.4 x 56.0mm |
Диапазон рабчоих температур | –10 °C to +55 °C |
Вес | 1.57 kg |
Вес брутто | 2.84 kg |
Код категории | NVR |
Полное подробное описание | Channels 16|Drives/bays 2|Desktop/pedestal|Rack 1U|Integrated LAN Gigabit|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|1xRS232|1xUSB 2.0|1xUSB 3.0|1xRJ45|1xRS-485|4xAlarm In|2xAlarm Out|Power supply requirements 12 VDC, 4 A|Power consumption 10 Watts|Dim. 375.0 × 284.4 x 56.0mm|Temp. range –10 °C to +55 °C |
