Channels 32 | Drives/bays 4 | Desktop/pedestal | Integrated LAN Gigabit | 1x15pin D-sub | 1xHDMI | 1xAudio-In | 1xAudio-Out | 1xRS232 | 2xRJ45 | 16xAlarm In | 4xAlarm Out | Power supply requirements 100-240 VAC, 50 to 60HZ, 1.5A | Power consumption 48 Watts | Dim. 440 × 330 × 44 mm | Temp. range -10–55 °C
| Description | VIGI 32 Channel Network Video Recorder
Face Recognition: Enhances access management and maximizes security.
Smart Search by Motion and Object: Quickly find target footage for improved playback efficiency.
H.265+: Without using any extra bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
320 Mbps Incoming and Outgoing Bandwidth: Ensures your NVR manages more cameras with high resolutions.
Mass Storage: Supports 4× SATA, up to 10 TB each
16-ch@2MP/ 8-ch@4MP Decoding Capacity†: Allows you to enjoy more channels, live view, and playback at the same time.
1 HDMI and 1 VGA Interface: Supports independent video output.
16-Channel Simultaneous Playback: Replay the feed from up to 16 cameras at the same time, increase replay speed, and find events in the video schedule to easily review footage.
Plug & Play: Allows new and unused VIGI IP Cameras to be added automatically to the new NVR and activated instantly, making installation faster than ever before.
Remote Monitoring: The dedicated VIGI app, web UI, and VIGI Security Manager enable remote monitoring, providing ease and convenience.
Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere. Suitable for management.
ONVIF Ensures Compatibility: Easily adds IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility.r |
| Страница производителя | ww.tp-link.com/us/business-networking/vigi-network-video-recorder/vigi-nvr4032h/#specifications |
| Модель | VIGI NVR4032H |
| Количество каналов | 32 |
| Количество дисков/отсеков | 4 |
| Десктоп-/башенный тип | Yes |
| Интегрированная сетевая карта | Gigabit |
| 15-контактный разъем D-sub | 1 |
| Входные порты | 16 |
| Выходные порты | 4 |
| Аудио-вход | 1 |
| Аудио-выход | 1 |
| HDMI | 1 |
| RJ45 | 2 |
| RS232 | 1 |
| Требование к блоку/адаптеру питания | 100-240 VAC, 50 to 60HZ, 1.5A |
| Энергопотребление | 48 Watts |
| Размер (физические параметры) | 440 × 330 × 44 mm |
| Диапазон рабчоих температур | -10–55 °C |
| Вес | 4 kg |
| Вес брутто | 5.25 kg |
| Ширина коробки блока | 0.44 |
| Длина коробки блока | 0.53 |
| Высота коробки блока | 0.102 |
| Полное подробное описание | Channels 32|Drives/bays 4|Desktop/pedestal|Integrated LAN Gigabit|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|1xRS232|2xRJ45|16xAlarm In|4xAlarm Out|Power supply requirements 100-240 VAC, 50 to 60HZ, 1.5A|Power consumption 48 Watts|Dim. 440 × 330 × 44 mm|Temp. range -10–55 °C |
| Код категории | NVR |
