Mounting Type | Wall |
Housing material | Aluminium |
Product colour | White |
Form factor | Box |
DC output voltage | 12 |
Power consumption (max) | 12.95 W |
Power consumption (typical) | 5.4 W |
Power source type | PoE |
Security algorithms | TLS |
HTTPS encryption | Yes |
Operating relative humidity (H-H) | 10 - 85% |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 35 °C |
Storage temperature (T-T) | -40 - 65 °C |
Weight | 153 g |
Depth | 60 mm |
Width | 93 mm |
Height | 105 mm |
Networking standards | IEEE 802.3af |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Certification | EMC
EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2,
FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A),
KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A,
VCCI Class A
Safety
CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3,
IEC 62471 (exempt)
Network
NIST SP500-267 |
Wide Dynamic Range (WDR) | Yes |
Type | IP security camera |
Connectivity Technology | Wired |
Day/night mode | Yes |
Placement supported | Indoor |
Number of Cameras | 1 |
Built-in microphone | Yes |
Audio system full duplex | Yes |
Flash Memory | 512 MB |
INTERNAL MEMORY | 1024 MB |
COMPATIBLE MEMORY CARDS | MicroSDXC |
Card reader integrated | Yes |
USB Port | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Camera shutter speed | 1/19000 - 1/5 s |
Minimum illumination | 0.03 lx |
Lens viewing angle, vertical | 55° |
Lens viewing angle, horizontal | 103° |
Progressive Scan | Yes |
Sensor type | CMOS |
Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
Maximum Resolution | 1920 x 1080 pixels |
Video formats supported | H.264 |
Video compression formats | H.265 |
Privacy masking | Yes |
Frame rate | 30 fps |
Video streaming | Yes |
LED type | IR |
Night Vision | Yes |
Focal length range | 3.16 mm |
Fixed focal length | 2 mm |
