Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Ethernet/LAN |
PTZ-Modi | Digitale PTZ |
Design | |
form factor | Box |
attachment type | Wand |
Product color | Weiß |
International degree of protection (IP code) | IP66 |
IK-Kodex | IK10 |
Camera | |
minimum lighting | 0,1 Lux |
viewing angle (horizontal) | 90° |
viewing angle (vertical) | 49° |
image sensor | |
Image sensor size | 25,4 / 2,9 mm (1 / 2.9") |
Sensor-Typ | CMOS |
lens | |
focal range | 3 - 10.5 mm |
night vision | |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Supported video formats | H.264, H.265 |
Video compression formats | H.264, H.265, MPEG4 |
Supported graphic resolutions | 160 x 90 |
Up to 30 frames per second | 30 fps |
Audio | |
Audio-System | 2-Wege |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
storage medium | |
Flash memory | 512 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 4,4 W |
Power consumption (max.) | 6,6 W |
Power Consumption (Power over Ethernet (PoE)) | 4,5 W |
DC output volts | 10, 12, 15, 16, 24, 28 |
operating conditions | |
operating temperatur | -20 - 50 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 100% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 143 mm |
depth | 317 mm |
height | 108 mm |
Device width (incl. foot) | 143 mm |
Device depth (incl. foot) | 372 mm |
Device height (incl. foot) | 240 mm |
Weight (with stand) | 1,8 kg |
scope of delivery | |
number of cameras | 1 |
logistic data | |
Goods tariff number (HS) | 85258900 |
