Services | |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Nachtsicht |
Design | |
form factor | Box |
attachment type | Wand |
Product color | Schwarz, Weiß |
Camera | |
minimum lighting | 0,17 Lux |
viewing angle (horizontal) | 112° |
viewing angle (vertical) | 82° |
camera shutter speed | 1/33500 - 1/5 s |
image sensor | |
Image sensor size | 25,4 / 2,7 mm (1 / 2.7") |
Sensor-Typ | CMOS |
lens | |
focal range | 2.8 - 13 mm |
night vision | |
Video | |
Maximum resolution | 2592 x 1944 Pixel |
total megapixels | 5 MP |
Supported video formats | H.264, H.265 |
Video compression formats | MPEG4 |
Supported graphic resolutions | 160 x 120 |
Up to 30 frames per second | 30 fps |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
storage medium | |
Flash memory | 512 MB |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 4,4 W |
Power consumption (max.) | 6,6 W |
Power Consumption (Power over Ethernet (PoE)) | 4,5 W |
DC output volts | 10, 12, 15, 16, 24, 28 |
operating conditions | |
operating temperatur | -20 - 50 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 85% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 70 mm |
depth | 179 mm |
height | 59 mm |
Device width (incl. foot) | 70 mm |
Device depth (incl. foot) | 179 mm |
Device height (incl. foot) | 179 mm |
scope of delivery | |
number of cameras | 1 |
logistic data | |
Goods tariff number (HS) | 85258900 |
