Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Drinnen |
transmission technology | Kabelgebunden |
Eigenschaft | Integrierter Kartenleser |
PTZ-Modi | Digitale PTZ, Preset-Punkt |
Design | |
form factor | Box |
attachment type | Decke/Wand |
Product color | Schwarz, Weiß |
housing material | Aluminium |
Camera | |
minimum lighting | 0,005 Lux |
viewing angle (horizontal) | 121 - 26° |
viewing angle (vertical) | 64 - 15° |
Pixelgröße Kamera | 2,9 µm |
camera shutter speed | 1/37000 - 2 s |
image sensor | |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
lens | |
focal range | 2.8 - 13 mm |
night vision | |
LED Type | IR |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Video compression formats | H.264, H.265, M-JPEG, MPEG4 |
Up to 30 frames per second | 60 fps |
noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
gain control type | Auto |
Audio | |
Supported audio formats | AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM |
Noise Ratio (SNR) | 55 dB |
network | |
Ethernet interfaces type | Schnelles Ethernet, Gigabit Ethernet |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Flash memory | 8192 MB |
storage capacity | 1024 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
RS-485-Anschlüsse | 2 |
safety | |
Supported security algorithms | 802.1x RADIUS, EAP-TLS, HTTPS, PEAP, TLS |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 3,15 W |
Power consumption (max.) | 7,76 W |
Power Consumption (Power over Ethernet (PoE)) | 2,97 W |
DC output volts | 10, 28 |
operating conditions | |
operating temperatur | -10 - 55 °C |
Storage temperature range | -40 - 65 °C |
weight and dimensions | |
broad | 87 mm |
depth | 225 mm |
height | 235 mm |
Weight | 480 g |
scope of delivery | |
number of cameras | 1 |
