Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Draußen |
transmission technology | Kabelgebunden |
PTZ-Modi | Digitale PTZ |
Eigenschaft | HTTPS-Verschlüsselung |
number of languages | 12 |
Design | |
form factor | Bullet |
attachment type | Decke/Wand |
Product color | Weiß |
housing material | Aluminium, Kunststoff |
protective function | Staubresistent, Vandalismussicher, Wasserfest |
International degree of protection (IP code) | IP66, IP67 |
IK-Kodex | IK08 |
Camera | |
viewing angle (horizontal) | 130° |
viewing angle (vertical) | 81° |
white balance | Auto |
camera shutter speed | 1/38500 - 1/5 s |
image sensor | |
Sensor-Typ | CMOS |
lens | |
number of lenses | 1 |
Maximum f-number | 2,1 |
Fixed focal length | 2,4 mm |
Naheinstellgrenze | 0,5 m |
night vision | |
night vision distance | 20 m |
LED Type | IR |
infrared wavelength | 855 nm |
Video | |
Maximum resolution | 2304 x 1728 Pixel |
total megapixels | 4 MP |
Video compression formats | H.264, H.265, M-JPEG |
Supported graphic resolutions | 2668 x 1512, 2304 x 1728 |
Supported video modes | 1440p |
network | |
Ethernet interfaces type | Schnelles Ethernet |
mesh standard | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
Flash memory | 512 MB |
storage capacity | 1024 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | 802.1x RADIUS, EAP-TLS, HTTPS, SSH |
alert notification type | E-Mail |
energy | |
energy source | PoE |
Power consumption (standard operation) | 5 W |
Power consumption (max.) | 12,95 W |
operating conditions | |
operating temperatur | -30 - 50 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 100% |
weight and dimensions | |
diameter | 10,1 cm |
Length (mm) | 170 mm |
Weight | 491 g |
scope of delivery | |
number of cameras | 1 |
Technical details | |
Does not contain | BFR, PVC |
logistic data | |
Goods tariff number (HS) | 85258900 |
