Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | HTTPS-Verschlüsselung |
Design | |
form factor | Bullet |
attachment type | Wand- / Mast |
Product color | Weiß |
housing material | Aluminium, Polycarbonat (PC) |
protective function | Vandalismussicher |
International degree of protection (IP code) | IP67 |
IK-Kodex | IK10 |
Camera | |
minimum lighting | 0,01 Lux |
viewing angle (horizontal) | 117° |
viewing angle (vertical) | 59° |
Pixelgröße Kamera | 2,9 µm |
camera shutter speed | 1/71500 - 2 s |
image sensor | |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
Panoramakamera | |
Signal-Rausch-Verhältnis (SNR) (Panoramakamera) | 55 dB |
lens | |
Naheinstellgrenze | 0,5 m |
night vision | |
night vision distance | 40 m |
LED Type | IR |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
Video compression formats | AVC, H.264, H.265, HEVC, MPEG4 |
Up to 30 frames per second | 60 fps |
noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
network | |
Ethernet interfaces type | Schnelles Ethernet, Gigabit Ethernet |
mesh standard | IEEE 802.1x |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Flash memory | 8192 MB |
storage capacity | 1024 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | EAP-TLS, HTTPS, TLS |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 7,2 W |
Power consumption (max.) | 12,95 W |
Power Consumption (Power over Ethernet (PoE)) | 7,9 W |
DC output volts | 10, 28 |
operating conditions | |
operating temperatur | -40 - 60 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 100% |
humidity during storage | 5 - 95% |
weight and dimensions | |
diameter | 13,2 cm |
Length (mm) | 280 mm |
Weight | 1,2 kg |
scope of delivery | |
number of cameras | 1 |
