| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Betriebsanleitung |
| PTZ-Modi | Digitale PTZ |
| certification | UL/cUL, BIS, UKCA, CE, KC, EAC, VCCI, RCM |
| Design | |
| form factor | Bullet |
| attachment type | Wand |
| Product color | Schwarz, Weiß |
| housing material | Aluminium, Glas |
| protective function | Schlagfest |
| International degree of protection (IP code) | IP66, IP67 |
| IK-Kodex | IK10 |
| Camera | |
| minimum lighting | 0,02 Lux |
| rotation angle | 360° |
| viewing angle (horizontal) | 60 - 2.3° |
| viewing angle (vertical) | 39 - 1.3° |
| tilt angle range | 0 - 90° |
| swivel range | -180 - 180° |
| Pixelgröße Kamera | 2 µm |
| camera shutter speed | 1/143000 - 2 s |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 1,8 mm (1 / 1.8") |
| Sensor-Typ | CMOS |
| lens | |
| Optical zoom | 32x |
| number of lenses | 1 |
| focal range | 4.3 - 137 mm |
| Maximum f-number | 4 |
| Minimum f-number | 1,4 |
| Abstandsfeststellung (wide) | 87,7 m |
| Abstandsfeststellung (tele) | 2732,1 m |
| Abstandsbeobachtung (wide) | 34,8 m |
| Abstandsbeobachtung (tele) | 1084,2 m |
| Abstandserkennung (wide) | 17,5 m |
| Abstandserkennung (tele) | 546,4 m |
| Abstandsermittlung (wide) | 8,8 m |
| Abstandsermittlung (tele) | 273,2 m |
| Naheinstellgrenze | 1,2 m |
| night vision | |
| night vision distance | 100 m |
| LED Type | IR |
| infrared wavelength | 850 nm |
| Video | |
| Maximum resolution | 2880 x 1620 Pixel |
| total megapixels | 4 MP |
| Supported video formats | AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
| Supported graphic resolutions | 1280 x 800 (WXGA), 2880 x 2160 |
| Up to 30 frames per second | 90 fps |
| noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
| gain control type | Auto |
| image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
| Bitratenkontrolle | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Audio | |
| Supported audio formats | AAC-LC, ADPCM, G.711, G.726, LPCM, PCM |
| Samplerate | 48 kHz |
| Noise Ratio (SNR) | 55 dB |
| network | |
| Ethernet interfaces type | Schnelles Ethernet, Gigabit Ethernet |
| mesh standard | IEEE 802.1x, IEEE 802.3at, IEEE 802.3bt |
| streaming method | Multicasting |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 8192 MB |
| ROM capacity | 2048 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| alert notification type | E-Mail |
| Intelligent Video Surveillance (IVS) system properties | Erkennung von Menschen, Erkennung Leitungskreuzungen, Moving object, Fahrzeugerkennung |
| management functions | |
| energy | |
| energy source | PoE |
| Power consumption (standard operation) | 14,6 W |
| Power consumption (max.) | 51 W |
| operating conditions | |
| operating temperatur | -40 - 60 °C |
| Storage temperature range | -40 - 65 °C |
| Operating relative humidity | 10 - 100% |
| humidity during storage | 5 - 95% |
| weight and dimensions | |
| broad | 183 mm |
| depth | 411 mm |
| height | 183 mm |
| Weight | 3,2 kg |
| scope of delivery | |
| number of cameras | 1 |
| Supplied cables | LAN (RJ-45) |
| Technical details | |
| sustainability certificates | REACH, RoHS |
| Does not contain | PVC/BFR |
| Konformitätsbescheinigungen | REACH, RoHS |
