features | |
Type | Sensoreinheit |
Unterstützte Positionierung | Universal |
brand compatibility | Axis |
compatibility | F4105-SLRE |
Product color | Silber |
housing material | Edelstahl |
International degree of protection (IP code) | IP66, IP67, IP6K9K |
IK-Kodex | IK10 |
Eigenschaft | Schnellinstallationsanleitung |
image sensor | |
Objektivanschluss | M12 |
Image sensor size | 1/2.8" |
Sensor-Typ | CMOS |
focal range | 2.8 mm |
Blende (relative Öffnung) | 2 |
Auflösung | 1920 x 1080 Pixel |
angle of view, horizontal | 110° |
angle of view, vertical | 61° |
Ergonomics | |
Anzahl der Verbinder | 1 |
connections and interfaces | |
transmission technology | Kabelgebunden |
energy | |
Bemessungsleistung | 1,9 W |
Power consumption (standard operation) | 1,9 W |
Power consumption (max.) | 4,16 W |
weight and dimensions | |
cable length | 1 m |
broad | 114 mm |
depth | 57,8 mm |
height | 114 mm |
Weight | 452 g |
quantity per pack | 1 Stück(e) |
scope of delivery | |
operating conditions | |
operating temperatur | -30 - 55 °C |
Operating relative humidity | 10 - 100% |
Storage temperature range | -40 - 65 °C |
humidity during storage | 5 - 95% |
Technical details | |
Does not contain | PVC/BFR |
Garantiezeit | 5 Jahr(e) |
Konformitätsbescheinigungen | CE, KC, RCM, Gesetz über Handelsabkommen (TAA), UL, VCCI, WEEE, NFS |
