Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | IP-Adressen Filter |
number of languages | 12 |
Design | |
form factor | Box |
attachment type | Decke/Wand |
Product color | Weiß |
housing material | Aluminium, Kunststoff |
Camera | |
minimum lighting | 0,03 Lux |
viewing angle (horizontal) | 103° |
viewing angle (vertical) | 55° |
camera shutter speed | 1/19000 s |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 2,9 mm (1 / 2.9") |
Sensor-Typ | CMOS |
lens | |
number of lenses | 1 |
Fixed focal length | 3,16 mm |
night vision | |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
Video compression formats | AVC, H.264, H.265, HEVC, M-JPEG |
Supported graphic resolutions | 320 x 240, 640 x 360, 1280 x 960, 1920 x 1080 (HD 1080) |
Supported video modes | 1080p |
Up to 30 frames per second | 30 fps |
image quality adjustment | Helligkeit, Farbtiefe, Kontrast, Farbsättigung, Schärfe |
Bitratenkontrolle | Variable Bitrate (VBR) |
network | |
mesh standard | IEEE 802.1x |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
Flash memory | 512 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | EAP-TLS, HTTPS, SNMP |
energy | |
energy source | PoE |
Power consumption (standard operation) | 2,2 W |
Power consumption (max.) | 4,3 W |
Power Consumption (Power over Ethernet (PoE)) | 4,3 W |
DC output volts | 12 |
DC output current | 2,5 A |
operating conditions | |
operating temperatur | 0 - 35 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 85% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 60 mm |
depth | 93 mm |
height | 105 mm |
Weight | 137 g |
scope of delivery | |
number of cameras | 1 |
