Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | HTTPS-Verschlüsselung |
Design | |
form factor | Dome |
attachment type | Decke/Wand |
Product color | Weiß |
housing material | Kunststoff, Polycarbonat (PC) |
International degree of protection (IP code) | IP66 |
IK-Kodex | IK10 |
Camera | |
minimum lighting | 0,16 Lux |
rotation angle | 190° |
viewing angle (horizontal) | 102° |
viewing angle (vertical) | 73° |
tilt angle range | -10 - 80° |
swivel range | 0 - 190° |
camera shutter speed | 1/50000 - 1/5 s |
image sensor | |
Image sensor size | 25,4 / 2,7 mm (1 / 2.7") |
Sensor-Typ | CMOS |
lens | |
Minimum f-number | 2 |
Naheinstellgrenze | 1 m |
night vision | |
LED Type | IR |
Video | |
Maximum resolution | 2688 x 1512 Pixel |
Video compression formats | H.264, H.265 |
Up to 30 frames per second | 30 fps |
network | |
Ethernet interfaces type | Schnelles Ethernet |
mesh standard | IEEE 802.1x |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Flash memory | 8192 MB |
storage capacity | 1024 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | EAP-TLS, HTTPS |
energy | |
energy source | PoE |
Power Consumption (Power over Ethernet (PoE)) | 4,8 W |
operating conditions | |
operating temperatur | -40 - 50 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 100% |
humidity during storage | 5 - 95% |
weight and dimensions | |
height | 102 mm |
diameter | 14,9 cm |
Weight | 791 g |
scope of delivery | |
number of cameras | 1 |
