Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
PTZ-Modi | Digitale PTZ |
Eigenschaft | Betriebsanleitung |
number of languages | 12 |
Design | |
form factor | Dome |
attachment type | Decke/Wand |
Product color | Weiß |
International degree of protection (IP code) | IP66 |
IK-Kodex | IK10+ |
Camera | |
minimum lighting | 0,08 Lux |
rotation angle | 175° |
tilt angle range | -43 - 80° |
camera shutter speed | 1/91000 - 1 s |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 1,8 mm (1 / 1.8") |
Sensor-Typ | CMOS |
lens | |
Optical zoom | 2,6x |
number of lenses | 1 |
night vision | |
LED Type | IR |
Video | |
Maximum resolution | 2688 x 1512 Pixel |
total megapixels | 4 MP |
Video compression formats | H.264, H.265 |
Up to 30 frames per second | 60 fps |
image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
Bitratenkontrolle | Variable Bitrate (VBR) |
Audio | |
Supported audio formats | AAC-LC, ADPCM, G.711, G.726, OPUS, PCM |
network | |
mesh standard | IEEE 802.3at |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Flash memory | 8194 MB |
storage capacity | 2048 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | 802.1x RADIUS |
alert notification type | E-Mail |
energy | |
energy source | PoE |
Power consumption (standard operation) | 9 W |
Power consumption (max.) | 23 W |
operating conditions | |
operating temperatur | -50 - 60 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 10 - 100% |
humidity during storage | 5 - 95% |
weight and dimensions | |
diameter | 18,4 cm |
Weight | 2,1 kg |
scope of delivery | |
number of cameras | 1 |
