Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Nachhaltigkeitskonformität |
Design | |
form factor | Dome |
attachment type | Zimmerdecke |
Product color | Weiß |
International degree of protection (IP code) | IP66, IP67 |
IK-Kodex | IK09 |
Camera | |
rotation angle | 190° |
viewing angle (horizontal) | 108 -40° |
viewing angle (vertical) | 55 -23° |
Lens viewing angle, diagonal | 131 -46° |
tilt angle range | 25 - 95° |
swivel range | -90 - 90° |
Pixelgröße Kamera | 2,9 µm |
camera shutter speed | 1/28000 - 5 s |
image sensor | |
number of sensors | 4 |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
Panoramakamera | |
Sensortyp (Panoramakamera) | CMOS |
Anzahl der Sensoren (Panoramakamera) | 4 |
Größe des optischen Sensors (Panoramakamera) | 25,4 / 2,8 mm (1 / 2.8") |
Maximale Auflösung (Panoramakamera) | 1920 x 1080 Pixel |
Verschlusszeit der Kamera (Panoramakamera) | 1/31500 s |
Signal-Rausch-Verhältnis (SNR) (Panoramakamera) | 55 dB |
Brennweitenbereich (Panoramakamera) | 3.18 - 8.12 mm |
Betrachtungswinkel, vertikal (Panoramakamera) | 55,3° |
Betrachtungswinkel, horizontal (Panoramakamera) | 360° |
lens | |
number of lenses | 4 |
Focus | Mit Motor/von Hand |
night vision | |
LED Type | IR |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Supported video formats | H.264, H.265, M-JPEG |
Video compression formats | H.264, H.265, M-JPEG |
Up to 30 frames per second | 30 fps |
Audio | |
network | |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Flash memory | 8192 MB |
storage capacity | 2048 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
energy | |
energy source | PoE |
operating conditions | |
operating temperatur | -30 - 50 °C |
Storage temperature range | -40 - 65 °C |
weight and dimensions | |
Weight | 2 kg |
Technical details | |
sustainability certificates | CE, EAC, KC, UKCA, UL ECOLOGO, VCCI, cUL |
