Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Betriebsanleitung |
Design | |
form factor | Dome |
attachment type | Decke/Wand |
Product color | Schwarz, Weiß |
housing material | Aluminium |
protective function | Schockresistent |
International degree of protection (IP code) | IP66 |
IK-Kodex | IK10 |
Camera | |
minimum lighting | 0,02 Lux |
viewing angle (horizontal) | 58.7° |
viewing angle (vertical) | 35.7° |
tilt angle range | 0 - 180° |
incline speed | 350 °/Sekunde |
swivel range | 0 - 360° |
Webcam - Pan speed | 350 °/Sekunde |
camera shutter speed | 1/66500 - 2 s |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
Sensor-Typ | CMOS |
lens | |
Optical zoom | 32x |
digital zoom | 12x |
number of lenses | 1 |
focal range | 4.3 - 137.6 mm |
Maximum f-number | 4 |
Minimum f-number | 1,4 |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
Supported video formats | AVC, H.264, H.265, HEVC, M-JPEG, MPEG4 |
Supported graphic resolutions | 320 x 180, 1920 x 1080 (HD 1080) |
Supported video modes | 1080p |
Up to 30 frames per second | 60 fps |
image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
Bitratenkontrolle | Variable Bitrate (VBR) |
Audio | |
Audio-System | 2-Wege |
Supported audio formats | ADPCM, LC-AAC, LPCM, PCM |
Samplerate | 48 kHz |
network | |
Ethernet interfaces type | Schnelles Ethernet |
mesh standard | IEEE 802.1x, IEEE 802.3at |
streaming method | Multicasting |
storage medium | |
Compatible memory cards | SD, SDHC, SDXC |
Flash memory | 512 MB |
storage capacity | 1024 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 10,5 W |
Power consumption (max.) | 19 W |
operating conditions | |
operating temperatur | -30 - 55 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 100% |
weight and dimensions | |
broad | 188 mm |
depth | 188 mm |
height | 217 mm |
Weight | 2,5 kg |
scope of delivery | |
number of cameras | 1 |
logistic data | |
Goods tariff number (HS) | 85258900 |
