| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Betriebsanleitung |
| processor | ARTPEC-7 |
| number of languages | 11 |
| Design | |
| form factor | Dome |
| attachment type | Zimmerdecke |
| Product color | Schwarz, Weiß |
| housing material | Aluminium, Polycarbonat (PC) |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK08, IK10 |
| Camera | |
| minimum lighting | 0,01 Lux |
| viewing angle (horizontal) | 58.3 – 2.4 |
| viewing angle (vertical) | 34.9 – 1.3 |
| tilt angle range | 20 - 90° |
| incline speed | 500 °/Sekunde |
| swivel range | 0 - 360° |
| Webcam - Pan speed | 700 °/Sekunde |
| camera shutter speed | 1/66500 - 2 s |
| image sensor | |
| Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
| Sensor-Typ | CMOS |
| lens | |
| Optical zoom | 32x |
| digital zoom | 12x |
| number of lenses | 1 |
| focal range | 4.3 - 137.6 mm |
| Maximum f-number | 4 |
| Minimum f-number | 1,4 |
| night vision | |
| night vision distance | 250 m |
| LED Type | IR |
| infrared wavelength | 850 nm |
| Video | |
| Maximum resolution | 1920 x 1080 Pixel |
| Video compression formats | H.264, H.265, M-JPEG |
| Supported graphic resolutions | 320 x 180, 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Up to 30 frames per second | 60 fps |
| image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
| Audio | |
| Audio-System | 2-Wege |
| network | |
| mesh standard | IEEE 802.1x, IEEE 802.3at |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 512 MB |
| storage capacity | 1024 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| alert notification type | E-Mail |
| energy | |
| energy source | AC, PoE |
| AC input voltage | 100 - 240 V |
| Power consumption (standard operation) | 13,5 W |
| Power consumption (max.) | 51 W |
| Power Consumption (Power over Ethernet (PoE)) | 37 W |
| operating conditions | |
| operating temperatur | -30 - 50 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 100% |
| humidity during storage | 5 - 95% |
| weight and dimensions | |
| height | 241 mm |
| diameter | 16,5 cm |
| Weight | 3 kg |
| scope of delivery | |
| number of cameras | 1 |
| Other functions | |
| Does not contain | PVC |
| Garantiezeit | 5 Jahr(e) |
