Camera | |
transmission technology | Kabelgebunden |
Eigenschaft | Software-CD |
Surveillance Camera Form Factor | Patrone (Form) |
camera surface | BNC |
Kamerkabel Länge | 18 m |
Unterstützte Positionierung | Drinnen/Draußen |
number of cameras | 4 |
night vision distance | 30 m |
Sensor-Typ | CMOS |
Image sensor size | 25,4 / 4 mm (1 / 4") |
LED Type | IR |
Betrachtungswinkel | 65° |
camera shutter speed | 1/50 - 1/100000 s |
International degree of protection (IP code) | IP66 |
Recorder | |
number of channels | 8 Kanäle |
Storage media type | HDD |
Installed operating system | Linux Embedded |
BNC Eingänge | 8 |
Number of VGA (D-Sub) connections | 1 |
Number of USB 2.0 ports | 2 |
HDD size | 3.5" |
Maximum supported number of HDD | 1 |
HDD capacity | 6 TB |
Supported network protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP, HTTPS |
LED indicators | HDD, LAN, Leistung |
Line-Eingänge (RCA) | 1 |
Line outputs (RCA) | 1 |
Maximum HDD storage | 6 TB |
Number of HDMI ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 1 |
Playback solutions supported | 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
network | |
Ethernet interfaces type | Schnelles Ethernet |
energy | |
energy source | Gleichstrom |
DC output volts | 12 |
Camera power consumption (standby) | 4 W |
Recorder power consumption (typical) | 8 W |
system requirement | |
Supported mobile operating systems | Android, iOS |
operating conditions | |
operating temperatur | -40 - 80 °C |
Operating relative humidity | 10 - 90% |
Technical details | |
Video compression formats | H.264, MP4 |
Supported audio formats | G.711 A-law |
Supported video modes | 720p |
Country of origin | China |
Product color | Schwarz, Weiß |
Palettenhöhe net | 120 cm |
certification | CE |
weight and dimensions | |
cam width | 6,4 cm |
cam depth | 16,5 cm |
cam height | 6,4 cm |
recorder width | 22 cm |
recorder depth | 22,2 cm |
recorder height | 4,5 cm |
broad | 225 mm |
depth | 430 mm |
height | 221 mm |
package weight | 4 kg |
scope of delivery | |
Supplied cables | Gleichstrom |
packaging type | Box |
