International Protection (IP) code | IP67 |
Product colour | White |
Housing material | Metal, Plastic |
Form factor | Dome |
Degree of protection IK | IK10 |
SMD Plus | Yes |
Mounting Type | Wall/ceiling |
Power consumption (max) | 5 W |
Power source type | DC, PoE |
Power consumption (typical) | 2.3 W |
DC output voltage | 12, 48 |
Power consumption (Power over Ethernet (PoE)) | 6.1 W |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -40 - 60 °C |
Web-based management | Yes |
Web browser | Yes |
Weight | 340 g |
Width | 109.9 mm |
Height | 81 mm |
Depth | 109.9 mm |
Bluetooth | No |
Ethernet interface type | 10 Megabit Ethernet |
Wi-Fi | No |
4G LTE | N |
Mobile operating systems supported | iOS |
Wide Dynamic Range (WDR) | 120 dB |
Type | IP security camera |
Connectivity Technology | Wired |
Signal-to-Noise Ratio (SNR) | 56 dB |
Placement supported | Outdoor |
Number of Cameras | 1 |
Built-in microphone | Yes |
Audio codecs | G.711a, G.711Mu, G.726, PCM |
Built-in loudspeaker | No |
Two-way talk | N |
ROM capacity | 128 MB |
RAM Capacity | 256 MB |
Maximum memory card size | 256 GB |
COMPATIBLE MEMORY CARDS | MicroSDXC |
Number of memory card slots | 1 |
Alarm input/output | N |
Minimum illumination | 0.007 lx |
Adjustment shutter speed | Auto/Manual |
Camera shutter speed | 1/3 - 1/100000 s |
Motion Detection | Yes |
People detection | Yes |
Horizontal rotation angle | 0 - 355° |
Viewing angle, diagonal | 132° |
Lens viewing angle, vertical | 58° |
Vertical rotation angle | 0 - 65° |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Sensor type | HD CMOS |
Number of sensors | 1 |
Video compression formats | H.265+ |
Maximum Resolution | 2960 x 1668 px |
Frame rate | 20 fps |
Total megapixels | 5 MP |
Video streaming | Yes |
LED type | IR |
Night vision distance | 30 m |
Number of illumination LEDs | 3 |
Night Vision | Yes |
Focal length range | 2.8 mm |
Maximum aperture number | 1.6 |
Aperture type | Permanent |
Number of lenses | 1 |
Lens type | Fixed focal length lens |
Closest focusing distance | 1.1 m |
