| Product colour | Black |
| Form factor | Dome |
| I code | IK08 |
| International Protection (IP) code | IP66 |
| Mounting Type | Ceiling/wall |
| LED indicators | Yes |
| Power source type | DC, PoE |
| Power consumption (max) | 13 W |
| Power consumption (typical) | 4 W |
| Intelligent Video Surveillance (IVS) system features | Crossing line |
| Alarm output channels | 1 |
| Alarm input channels | 1 |
| Video motion detection | Yes |
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Management software | DMSS; DSS Pro |
| Web-based management | Yes |
| Diameter | 12.8 cm |
| Height | 65.7 mm |
| Weight | 500 g |
| Number of users | 20 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Mobile operating systems supported | iOS |
| Certification | CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035
CE-LVD: EN 62368-1
FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4 |
| Placement supported | Indoor & outdoor |
| PTZ control | Yes |
| PTZ modes | 8 Tour |
| Type | IP security camera |
| Preset points | Yes |
| Connectivity Technology | Wired |
| PTZ protocols | DH-SD |
| Wide Dynamic Range (WDR) | Yes |
| Alarm input/output | Yes |
| PACKAGE WEIGHT | 700 g |
| Number of Cameras | 1 |
| Audio detection | Yes |
| Audio input channels | 1 channels |
| Audio output channels | 1 channels |
| ROM capacity | 256 MB |
| RAM Capacity | 512 MB |
| Maximum memory card size | 512 GB |
| Built-in HDD | No |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Tilt angle range | 5 - 90° |
| Pan preset speed | 0.1 °/sec |
| Camera shutter type | Electronic |
| Camera shutter speed | 1 - 1/30000 s |
| White balance | Natural |
| Minimum illumination | 0.0005 lx |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Pan range | 0 - 355° |
| Tilt preset speed | 0.1 °/sec |
| Tilt manual speed | 0.1 - 30 °/sec |
| Pan manual speed | 0.1 - 70 °/sec |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 28 mm (1 / 28") |
| Progressive Scan | Yes |
| Noise reduction | Yes |
| Video streaming | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720) |
| Video compression formats | H.264+ |
| Image stabilizer | Yes |
| Gain control type | Auto/Manual |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Maximum Resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Frame rate | 30 fps |
| Region of Interest (ROI) encoding | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Night vision distance | 20 m |
| LED type | IR |
| Night Vision | Yes |
| Infra-red LEDs life | 3 h |
| Auto focus | Yes |
| Digital zoom | 16x |
| Identify distance (wide) | 24 m |
| Observe distance (wide) | 94.8 m |
| Closest focusing distance | 0.2 m |
| Maximum aperture number | 2.7 |
| Number of lenses | 1 |
| Recognize distance (wide) | 48 m |
| Optical zoom | 4x |
| Focus | Motorized/Manual |
| Detect distance (wide) | 240 m |
| Focal length range | 2.8 - 12 mm |
| Minimum aperture number | 1.8 |
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 55 dB |
