Product colour | White |
Housing material | Metal, Plastic |
International Protection (IP) code | IP67 |
Mounting Type | Ceiling |
Form factor | Dome |
Power consumption (typical) | 2.2 W |
Power source type | DC |
Power consumption (max) | 7.1 W |
DC output voltage | 12 |
Storage temperature (T-T) | -40 - 60 °C |
Operating temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Dedicated application | DMSS (Android, iOS) |
Diameter | 109,9 mm |
Height | 102.2 mm |
Weight | 353 g |
Networking standards | IEEE 802.11g |
Wi-Fi | Yes |
Mobile operating systems supported | Android |
Certification | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU |
Light alarm | Yes |
Connectivity Technology | Wired |
Placement supported | External / Internal |
Audible alarm | Yes |
Human detection | Yes |
Type | IP security camera |
Number of Cameras | 1 |
Audio formats supported | PCM |
Built-in microphone | Yes |
Built-in loudspeaker | Yes |
Maximum memory card size | 256 GB |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Adjustment shutter speed | Auto/Manual |
Lens viewing angle, horizontal | 78° |
Lens viewing angle, vertical | 41° |
Camera shutter speed | 1/3 - 1/100000 s |
Viewing angle, diagonal (2.8mm lens) | 115° |
Viewing angle, horizontal (2.8mm lens) | 98° |
Viewing angle, diagonal | 94° |
Viewing angle, vertical (2.8mm lens) | 55° |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Sensor type | CMOS |
Supported graphics resolutions | 2560 x 1440 |
Video compression formats | H.264 |
Maximum Resolution | 2560 x 1440 pixels |
Frame rate | 30 fps |
Video streaming | Yes |
Region of Interest (ROI) encoding | Yes |
Bit rate | H.264: 32 - 4096Kbps; H.265: 12 - 4096Kbps |
Total megapixels | 4 MP |
LED type | IR / White light LED |
Night vision distance | 30 m |
Number of illumination LEDs | 2 |
Night Vision | Yes |
Focal length range | 2.8 - 3.6 mm |
Maximum aperture number | 1.6 |
