Housing material | Metal |
Mounting Type | Ceiling |
International Protection (IP) code | IP67 |
Product colour | White |
Form factor | Turret |
DC output voltage | 12 |
Power consumption (typical) | 6.9 W |
Power source type | DC, PoE |
Video motion detection | Yes |
Security algorithms | HTTPS |
Storage temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Web browser | Yes |
Height | 108.3 mm |
Diameter | 12.2 cm |
Depth | 122 mm |
Width | 122 mm |
Weight | 690 g |
Ethernet LAN | Yes |
Number of users | 20 user(s) |
Streaming method | Multicast |
Ethernet interface type | Fast Ethernet |
Quality of Service (QoS) support | Yes |
Networking standards | IEEE 802.3af |
Mobile operating systems supported | iOS |
Certification | CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B |
Dynamic range | 120 dB |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Placement supported | Indoor & outdoor |
Connectivity Technology | Wired |
Type | IP security camera |
PACKAGE WEIGHT | 870 g |
Number of Cameras | 1 |
INTERNAL MEMORY | 128 MB |
ROM capacity | 128 MB |
Maximum memory card size | 256 GB |
Built-in HDD | No |
Card reader integrated | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Ethernet LAN (RJ-45) ports | 1 |
Lens viewing angle, vertical | 55 - 18° |
Lens viewing angle, diagonal | 116 - 36° |
Lens viewing angle, horizontal | 98 - 31° |
Angle of rotation | 360° |
Camera shutter speed | 1/3 - 1/100000 s |
White balance | Auto |
Minimum illumination | 0.03 lx |
Adjustment shutter speed | Auto/Manual |
Pan range | 0 - 355° |
Tilt angle range | 0 - 78° |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Frame rate | 30 fps |
Gain control type | Auto/Manual |
Video compression formats | M-JPEG |
Smart IR | Yes |
Highlight Compensation (HLC) | Yes |
Privacy masking | Yes |
Total megapixels | 4 MP |
Video formats supported | H.265 |
Bit rate | H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps |
Video streaming | Yes |
Back Light Compensation (BLC) | Yes |
Supported video modes | 1080p |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Region of Interest (ROI) encoding | Yes |
Noise reduction | Yes |
Video recording | Yes |
Noise reduction technology | 3D noise reduction |
Supported graphics resolutions | 704 x 480 |
Maximum Resolution | 2688 x 1520 pixels |
Night vision distance | 50 m |
LED type | IR |
Number of illumination LEDs | 2 |
Night Vision | Yes |
Identify distance (wide) | 6.6 m |
Observe distance (wide) | 26.4 m |
Recognize distance (tele) | 40 m |
Number of lenses | 1 |
Closest focusing distance | 0.8 m |
Observe distance (tele) | 80 m |
Detect distance (wide) | 66 m |
Maximum aperture number | 1.7 |
Recognize distance (wide) | 13.2 m |
Identify distance (tele) | 20 m |
Focal length range | 2.8 - 12 mm |
Detect distance (tele) | 200 m |
Number of Privacy masking areas (panoramic camera) | 4 |
