| Housing material | Plastic |
| Form factor | Turret |
| Mounting Type | Ceiling |
| Product colour | White |
| International Protection (IP) code | IP67 |
| Power source type | DC, PoE |
| Power consumption (typical) | 6.9 W |
| DC output voltage | 12 |
| Video motion detection | Yes |
| Security algorithms | HTTPS |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Web browser | Yes |
| Height | 108.3 mm |
| Width | 122 mm |
| Depth | 122 mm |
| Weight | 690 g |
| Diameter | 12.2 cm |
| Networking standards | IEEE 802.3af |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Number of users | 20 user(s) |
| Mobile operating systems supported | iOS |
| Certification | CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B |
| Dynamic range | 120 dB |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Connectivity Technology | Wired |
| PACKAGE WEIGHT | 870 g |
| Number of Cameras | 1 |
| ROM capacity | 128 MB |
| Maximum memory card size | 256 GB |
| INTERNAL MEMORY | 128 MB |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| White balance | Auto |
| Adjustment shutter speed | Auto/Manual |
| Pan range | 0 - 355° |
| Minimum illumination | 0.03 lx |
| Tilt angle range | 0 - 78° |
| Lens viewing angle, diagonal | 116 - 36° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, vertical | 55 - 18° |
| Angle of rotation | 360° |
| Lens viewing angle, horizontal | 98 - 31° |
| Progressive Scan | Yes |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Supported graphics resolutions | 1280 x 720 (HD 720) |
| Supported video modes | 720p |
| Frame rate | 30 fps |
| Video formats supported | H.264 |
| Video streaming | Yes |
| Bit rate | H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps |
| Maximum Resolution | 2688 x 1520 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.265 |
| Back Light Compensation (BLC) | Yes |
| Privacy masking | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
| Video recording | Yes |
| Gain control type | Auto/Manual |
| Noise reduction technology | 3D noise reduction |
| Noise reduction | Yes |
| Highlight Compensation (HLC) | Yes |
| Night vision distance | 50 m |
| LED type | IR |
| Night Vision | Yes |
| Number of illumination LEDs | 2 |
| Recognize distance (tele) | 40 m |
| Identify distance (wide) | 6.6 m |
| Recognize distance (wide) | 13.2 m |
| Detect distance (wide) | 66 m |
| Maximum aperture number | 1.7 |
| Number of lenses | 1 |
| Detect distance (tele) | 200 m |
| Observe distance (tele) | 80 m |
| Closest focusing distance | 0.8 m |
| Focal length range | 2.8 - 12 mm |
| Identify distance (tele) | 20 m |
| Observe distance (wide) | 26.4 m |
| Number of Privacy masking areas (panoramic camera) | 4 |
