| Form factor | Dome |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Mounting Type | Ceiling |
| Product colour | Black |
| Power consumption (max) | 8.6 W |
| Power consumption (Power over Ethernet (PoE)) | 5.8 W |
| Power consumption (typical) | 4.5 W |
| DC output voltage | 12 |
| Power source type | DC, PoE |
| Video motion detection | Yes |
| Mirror | Yes |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Built-in siren | Yes |
| Intelligent Video Surveillance (IVS) system features | Tripwire |
| Security algorithms | HTTPS |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -40 - 60 °C |
| Management software | Smart PSS, DSS, DMSS |
| Web browser | Yes |
| Height | 110.9 mm |
| Diameter | 12.2 cm |
| Weight | 750 g |
| Number of users | 20 user(s) |
| Wi-Fi | No |
| Streaming method | Multicast |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Bluetooth | No |
| Networking standards | IEEE 802.1x |
| Mobile operating systems supported | Android |
| Certification | CE-LVD: EN62368-1, CE-EMC, FCC |
| Wide Dynamic Range (WDR) | Yes |
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Infrared (IR) cut-off filter | Yes |
| Connectivity Technology | Wired |
| PACKAGE WEIGHT | 920 g |
| Manual | Yes |
| Number of Cameras | 1 |
| Audio input channels | 1.0 channels |
| Voice Codecs | PCM |
| Signal-to-Noise Ratio (SNR) | 56 dB |
| Audio output channels | 1.0 channels |
| Built-in microphone | Yes |
| Maximum memory card size | 2 GB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| ROM capacity | 256 MB |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Minimum illumination | 0.0004 lx |
| Camera shutter type | Electronic |
| White balance | Auto |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 125° |
| Pan range | 0 - 360° |
| Angle of rotation | 360° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 106° |
| Adjustment shutter speed | Auto/Manual |
| Camera pan control | Yes |
| Lens viewing angle, vertical | 55° |
| Tilt angle range | 0 - 78° |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Progressive Scan | Yes |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Back Light Compensation (BLC) | Yes |
| Bit rate | 3 kbps - 16384 kbps |
| Privacy masking | Yes |
| Frame rate | 30 fps |
| Supported video modes | 480p |
| Video formats supported | H.265+ |
| Smart IR | Yes |
| Region of Interest (ROI) encoding | Yes |
| Video compression formats | M-JPEG |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Gain control type | Auto/Manual |
| Highlight Compensation (HLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Video streaming | Yes |
| Total megapixels | 8 MP |
| Noise reduction | Yes |
| Supported graphics resolutions | 640 x 480 (VGA) |
| Maximum Resolution | 3840 x 2160 pixels |
| Night vision distance | 30 m |
| Night Vision | Yes |
| Number of illumination LEDs | 1 |
| LED type | IR |
| Fixed focal length | 2.8 mm |
| Observe distance (wide) | 26.4 m |
| Maximum aperture number | 1 |
| Number of lenses | 1 |
| Detect distance (wide) | 66 m |
| Closest focusing distance | 1.5 m |
| Identify distance (wide) | 6.6 m |
| Recognize distance (wide) | 13.2 m |
