| Housing material | Metal |
| Mounting Type | Ceiling |
| Form factor | Dome |
| Product colour | White |
| International Protection (IP) code | IP67 |
| DC output voltage | 12 |
| Power source type | DC, PoE |
| Power consumption (typical) | 7.2 W |
| Video motion detection | Yes |
| Intelligent Video Surveillance (IVS) system features | Crossing line |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Web browser | Yes |
| Diameter | 10.6 cm |
| Weight | 550 g |
| PACKAGE WEIGHT | 710 g |
| Height | 93.6 mm |
| Streaming method | Multicast |
| Number of users | 20 user(s) |
| Networking standards | IEEE 802.3af |
| Ethernet LAN | Yes |
| Quality of Service (QoS) support | Yes |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet |
| Bluetooth | No |
| Mobile operating systems supported | Android |
| Certification | CE-LVD: EN60950-1CE-EMC: Electromagnetic Compatibility Directive 2014/30/EUFCC: 47 CFR FCC Part 15, Subpart BUL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Placement supported | Indoor & outdoor |
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity Technology | Wired |
| Number of Cameras | 1 |
| Voice Codecs | AAC |
| Built-in microphone | Yes |
| INTERNAL MEMORY | 512 MB |
| ROM capacity | 128 MB |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| White balance | Manual |
| Minimum illumination | 0.005 lx |
| Angle of rotation | 360° |
| Camera shutter speed | 1/3 s–1/100000 s |
| Camera shutter type | Electronic |
| Pan range | 0 - 360° |
| Adjustment shutter speed | Auto/Manual |
| Tilt angle range | 0 - 78° |
| Lens viewing angle, horizontal | 102° |
| Lens viewing angle, vertical | 71° |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Progressive Scan | Yes |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Number of effective pixels (H x V) | 2592 x 1944 pixels |
| Bit rate | 32 Kbps–8192 Kbps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Total megapixels | 5 MP |
| Privacy masking | Yes |
| Noise reduction technology | 3D noise reduction |
| Video streaming | Yes |
| Region of Interest (ROI) encoding | Yes |
| Gain control type | Auto/Manual |
| Noise reduction | Yes |
| Frame rate | 60 fps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Video compression formats | H.264 |
| Flip & mirror | Yes |
| Supported graphics resolutions | 640 x 480 (VGA) |
| Maximum Resolution | 2592 x 1944 pixels |
| Number of illumination LEDs | 2 |
| Night vision distance | 50 m |
| LED type | IR |
| Night Vision | Yes |
| Maximum aperture number | 1.6 |
| Number of lenses | 1 |
| Fixed focal length | 2.8 mm |
