Number of video streams | 2 |
Lens mount interface | M12 |
I code | IK10 |
Form factor | Bullet |
International Protection (IP) code | IP67 |
Protection features | Waterproof |
Housing material | Metal |
Mounting Type | Ceiling/wall |
Product colour | Black |
DC output voltage | 12 |
Power consumption (typical) | 2.6 W |
Power consumption (max) | 7 W |
Power consumption (Power over Ethernet (PoE)) | 8.3 W |
Power source type | DC, PoE |
Alarm output channels | 1 |
Alarm input channels | 1 |
Network access storage (NAS) | Yes |
Intelligent Video Surveillance (IVS) system features | Intrusion |
Privacy protection | Yes |
Mirror | Yes |
Video motion detection | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -40 - 60 °C |
Management software | Smart PSS, DSS, DMSS |
Web browser | Yes |
Height | 90.7 mm |
Width | 90.7 mm |
Length | 238.5 mm |
Weight | 720 g |
Number of users | 20 user(s) |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
Client interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Mobile operating systems supported | iOS |
Certification | CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Alarm input/output | Yes |
Placement supported | Indoor & outdoor |
Type | IP security camera |
Dynamic range | 120 dB |
Connectivity Technology | Wired |
Built-in light | Yes |
PACKAGE WEIGHT | 970 g |
Number of Cameras | 1 |
Audio input channels | 1.0 channels |
Signal-to-Noise Ratio (SNR) | 56 dB |
Voice Codecs | G.711a |
Built-in microphone | Yes |
Audio output channels | 1.0 channels |
Built-in HDD | No |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 256 GB |
ROM capacity | 128 MB |
Card reader integrated | Yes |
RAM Capacity | 256 MB |
Ethernet LAN (RJ-45) ports | 1 |
White balance | Manual |
Minimum illumination | 0 lx |
Adjustment shutter speed | Auto/Manual |
Angle of rotation | 360° |
Camera shutter type | Electronic |
Camera shutter speed | 1/3 - 1/100000 s |
Pan range | 0 - 360° |
Lens viewing angle, horizontal | 55° |
Lens viewing angle, diagonal | 62° |
Lens viewing angle, vertical | 31° |
Number of Privacy masking areas | 4 |
Tilt angle range | 0 - 90° |
Browser supported | IE: IE8, IE9, IE11 Chrome Firefox, Safari |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Sensor type | CMOS |
Progressive Scan | Yes |
Number of sensors | 1 |
Video compression formats | H.264+ |
Noise reduction | Yes |
Smart IR | Yes |
Video streaming | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Bit rate | 12 Kbps - 8192 Kbps |
Total megapixels | 8 MP |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Frame rate | 30 fps |
Privacy masking | Yes |
Gain control type | Auto/Manual |
Supported graphics resolutions | 704 x 576 |
Maximum Resolution | 3840 x 2160 pixels |
Night vision distance | 50 m |
LED type | IR/White |
Number of illumination LEDs | 4 |
B/W night vision distance | 60 m |
Night Vision | Yes |
Fixed focal length | 3.6 mm |
Maximum aperture number | 1.6 |
Identify distance | 15.5 m |
Observe distance | 61.9 m |
Detect distance | 154.7 m |
Recognize distance | 30.9 m |
Number of lenses | 1 |
Closest focusing distance | 3.5 m |
