Mounting Type | Ceiling/Wall/Pole |
International Protection (IP) code | IP67 |
Protection features | Dust resistant |
Form factor | Dome |
Product colour | White |
Power source type | DC, PoC |
Power consumption (typical) | 2.6 W |
DC output voltage | 12 |
Intelligent Video Surveillance (IVS) system features | Tripwire |
Video motion detection | Yes |
Active tampering alarm | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -40 - 55 °C |
Storage temperature (T-T) | -40 - 60 °C |
Management software | Smart PSS; DSS; DMSS |
Web browser | Yes |
Width | 99.1 mm |
Weight | 480 g |
Diameter | 12.2 cm |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Streaming method | Multicast |
Number of users | 20 user(s) |
Quality of Service (QoS) support | Yes |
Mobile operating systems supported | Android |
Certification | CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
Built-in light | Yes |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Infrared (IR) cut-off filter | Yes |
Placement supported | Outdoor |
Connectivity Technology | Wired |
PACKAGE WEIGHT | 620 g |
Number of Cameras | 1 |
Audio formats supported | PCM |
Signal-to-Noise Ratio (SNR) | 56 dB |
INTERNAL MEMORY | 256 MB |
ROM capacity | 128 MB |
Ethernet LAN (RJ-45) ports | 1 |
White balance | Regional custom |
Camera shutter type | Electronic |
Camera shutter speed | 1/3 –1/100000 |
Angle of rotation | 360° |
Tilt angle range | 0 - 78° |
Pan range | 0 - 360° |
Sensor type | CMOS |
Number of sensors | 1 |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Supported graphics resolutions | 704 x 480 |
Video compression formats | H.264B |
Video streaming | Yes |
Back Light Compensation (BLC) | Yes |
Region of Interest (ROI) encoding | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Flip & mirror | Yes |
Highlight Compensation (HLC) | Yes |
Privacy masking | Yes |
Total megapixels | 8 MP |
Maximum Resolution | 3840 x 2160 pixels |
Gain control type | Auto/Manual |
LED type | IR |
Night vision distance | 30 m |
Night Vision | Yes |
Number of lenses | 2.8 |
Minimum aperture number | 1.6 |
