Mounting Type | Ceiling/Wall/Pole |
Product colour | White |
International Protection (IP) code | IP67 |
Form factor | Dome |
Housing material | Metal |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 7.3 W |
Power consumption (typical) | 2.6 W |
Power source type | DC, PoE |
AC input voltage | 12 V |
Power consumption (max) | 6 W |
Digital watermark | Yes |
Intelligent Video Surveillance (IVS) system features | Intrusion |
Mirror | Yes |
IP address filtering | Yes |
Video motion detection | Yes |
Storage temperature (T-T) | -40 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Weight | 685 g |
Depth | 122 mm |
Width | 122 mm |
Height | 108.3 mm |
Number of users | 20 user(s) |
Streaming method | Multicast |
Networking standards | IEEE 802.3af |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Mobile operating systems supported | Android |
Placement supported | Outdoor |
Wide Dynamic Range (WDR) | No |
Connectivity Technology | Wired |
Type | IP security camera |
PACKAGE WEIGHT | 828 g |
Number of Cameras | 1 |
Audio formats supported | G.711 μ-law |
Audio detection | Yes |
Signal-to-Noise Ratio (SNR) | 56 dB |
Built-in microphone | Yes |
Maximum memory card size | 256 GB |
ROM capacity | 128 MB |
Card reader integrated | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Ethernet LAN (RJ-45) ports | 1 |
Adjustment shutter speed | Auto/Manual |
Camera shutter speed | 1/3 - 1/100000 s |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Minimum illumination | 0.0007 lx |
White balance | Lamp |
Tilt angle range | 0 - 78° |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Number of sensors | 1 |
Sensor type | CMOS |
Gain control type | Auto/Manual |
Analog signal format system | PAL |
Noise reduction technology | 3D noise reduction |
Region of Interest (ROI) encoding | Yes |
Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
Total megapixels | 8 MP |
Frame rate | 30 fps |
Video compression formats | H.265+ |
Noise reduction | Yes |
Privacy masking | Yes |
Bit rate | 3 kbps–8192 kbps, H.265: 3 kbps–8192 kbps |
Maximum Resolution | 3840 x 2160 pixels |
Highlight Compensation (HLC) | Yes |
Back Light Compensation (BLC) | Yes |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Night Vision | Yes |
Number of illumination LEDs | 2 |
Night vision distance | 50 m |
LED type | IR |
Number of lenses | 1 |
Focal length range | 2.7 - 13.5 mm |
Maximum aperture number | 1.5 |
Closest focusing distance | 0.8 m |
