Number of video streams | 2 |
Lens mount interface | M12 |
Mounting Type | Ceiling/wall |
Fog proof | Yes |
International Protection (IP) code | IP67 |
Form factor | Turret |
Protection features | Waterproof |
Product colour | White |
Housing material | Metal |
Power consumption (Power over Ethernet (PoE)) | 10.6 W |
DC output voltage | 12 |
Power consumption (max) | 8.5 W |
Power source type | DC, PoE |
Power consumption (typical) | 4 W |
Intelligent Video Surveillance (IVS) system features | Intrusion |
Video motion detection | Yes |
Mirror | Yes |
Alarm input channels | 1 |
Alarm output channels | 1 |
Privacy protection | Yes |
Network access storage (NAS) | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -40 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Management software | Smart PSS, DSS, DMSS |
Web browser | Yes |
Weight | 885 g |
Height | 127.6 mm |
Diameter | 12.2 cm |
Client interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
Number of users | 20 user(s) |
Wi-Fi | No |
Bluetooth | No |
Networking standards | IEEE 802.3af |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Mobile operating systems supported | Android |
Certification | CE-LVD: EN 62368-1;
CE-EMC: Electromagnetc Compatbility Directve
2014/30/EU |
Day/night mode | Yes |
Alarm input/output | Yes |
Placement supported | Indoor & outdoor |
Dynamic range | 120 dB |
Built-in light | Yes |
Connectivity Technology | Wired |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
PACKAGE WEIGHT | 1.06 kg |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 56 dB |
Voice Codecs | G.711a |
Audio input channels | 1.0 channels |
Built-in speaker(s) | Yes |
Built-in microphone | Yes |
Audio output channels | 1.0 channels |
Built-in HDD | No |
ROM capacity | 256 MB |
RAM Capacity | 1000 MB |
Maximum memory card size | 512 GB |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Card reader integrated | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Adjustment shutter speed | Auto/Manual |
Lens viewing angle, vertical | 57 - 20° |
Camera shutter speed | 1/3 - 1/100000 s |
Camera shutter type | Electronic |
Lens viewing angle, horizontal | 113 - 36° |
Lens viewing angle, diagonal | 137 - 40° |
Pan range | 0 - 360° |
Number of Privacy masking areas | 4 |
Tilt angle range | 0 - 78° |
Angle of rotation | 360° |
Minimum illumination | 0 lx |
White balance | Natural |
Browser supported | IE: IE8, IE9, IE11 Chrome Firefox, Safari |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Number of sensors | 1 |
Sensor type | CMOS |
Video compression formats | H.265 |
Smart IR | Yes |
Region of Interest (ROI) encoding | Yes |
Noise reduction | Yes |
Privacy masking | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Total megapixels | 5 MP |
Gain control type | Auto/Manual |
Video streaming | Yes |
Noise reduction technology | 3D noise reduction |
Supported graphics resolutions | 704 x 480 |
Maximum Resolution | 2960 x 1668 pixels |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Bit rate | 3 kbps - 16384 kbps |
B/W night vision distance | 50 m |
Night Vision | Yes |
Number of illumination LEDs | 4 |
LED type | IR/White |
Night vision distance | 50 m |
Recognize distance (wide) | 13 m |
Detect distance (wide) | 65.2 m |
Closest focusing distance | 1.5 m |
Detect distance (tele) | 186.6 m |
Focal length range | 2.7 - 13.5 mm |
Identify distance (tele) | 18.7 m |
Observe distance (tele) | 74.6 m |
Observe distance (wide) | 26.1 m |
Number of lenses | 1 |
Maximum aperture number | 1 |
Recognize distance (tele) | 37.3 m |
Identify distance (wide) | 6.5 m |
Warnings | Avoid direct contact with water to prevent electrical damage. |
