| Lens mount interface | M12 |
| Number of video streams | 2 |
| Product colour | Black |
| Form factor | Bullet |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Protection features | Waterproof |
| Mounting Type | Ceiling/wall |
| Power source type | DC, PoE |
| Power consumption (typical) | 2.2 W |
| Power consumption (max) | 4.6 W |
| Power consumption (Power over Ethernet (PoE)) | 5.5 W |
| DC output voltage | 12 |
| Network access storage (NAS) | Yes |
| Video motion detection | Yes |
| Intelligent Video Surveillance (IVS) system features | Intrusion |
| Mirror | Yes |
| Privacy protection | Yes |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 60 °C |
| Management software | Smart PSS, DSS, DMSS |
| Web browser | Yes |
| Weight | 470 g |
| Width | 70 mm |
| Height | 70 mm |
| Length | 166.2 mm |
| Networking standards | IEEE 802.3af |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Number of users | 20 user(s) |
| Client interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| Mobile operating systems supported | Android |
| Certification | CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Built-in light | Yes |
| Connectivity Technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Type | IP security camera |
| Dynamic range | 120 dB |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Placement supported | Indoor & outdoor |
| PACKAGE WEIGHT | 590 g |
| Number of Cameras | 1 |
| Built-in microphone | Yes |
| Signal-to-Noise Ratio (SNR) | 56 dB |
| Voice Codecs | G.711a |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| RAM Capacity | 256 MB |
| Maximum memory card size | 256 GB |
| Built-in HDD | No |
| ROM capacity | 128 MB |
| Ethernet LAN (RJ-45) ports | 1 |
| Tilt angle range | 0 - 90° |
| Number of Privacy masking areas | 4 |
| White balance | Natural |
| Adjustment shutter speed | Auto/Manual |
| Camera shutter type | Electronic |
| Lens viewing angle, horizontal | 92° |
| Pan range | 0 - 360° |
| Minimum illumination | 0 lx |
| Lens viewing angle, diagonal | 110° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, vertical | 45° |
| Angle of rotation | 360° |
| Browser supported | IE: IE8, IE9, IE11 Chrome Firefox, Safari |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Number of sensors | 1 |
| Progressive Scan | Yes |
| Supported graphics resolutions | 352 x 240 |
| Maximum Resolution | 2960 x 1668 pixels |
| Bit rate | 12 Kbps - 8192 Kbps |
| Back Light Compensation (BLC) | Yes |
| Video compression formats | H.264+ |
| Privacy masking | Yes |
| Smart IR | Yes |
| Region of Interest (ROI) encoding | Yes |
| Noise reduction technology | 3D noise reduction |
| Video streaming | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Noise reduction | Yes |
| Total megapixels | 5 MP |
| Gain control type | Auto/Manual |
| Night vision distance | 30 m |
| LED type | IR/White |
| B/W night vision distance | 30 m |
| Number of illumination LEDs | 2 |
| Night Vision | Yes |
| Fixed focal length | 3.6 mm |
| Observe distance | 34.2 m |
| Closest focusing distance | 1.7 m |
| Maximum aperture number | 1.6 |
| Identify distance | 8.5 m |
| Number of lenses | 1 |
| Detect distance | 85.4 m |
| Recognize distance | 17.1 m |
