Mounting Type | Ceiling/wall |
Product colour | White |
I code | IK10 |
International Protection (IP) code | IP66 |
Form factor | Dome |
Housing material | Metal |
DC output current | 0.9 A |
Power consumption (Power over Ethernet (PoE)) | 12.5 W |
DC output voltage | 12 |
Power consumption (max) | 10.5 W |
Power source type | DC, PoE |
Heartbeat | Yes |
Digital watermark | Yes |
Video motion detection | Yes |
Mirror | Yes |
PASSWORD PROTECTION | Yes |
Anti-flicker | Yes |
Security algorithms | EAP-TLS |
IP address filtering | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Behavior analysis | Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection |
Web-based management | Yes |
Reset button | Yes |
Weight | 1.29 kg |
Height | 133.2 mm |
Diameter | 15.3 cm |
Number of users | 32 user(s) |
Bluetooth | No |
Networking standards | IEEE 802.3af |
Ethernet LAN | Yes |
Wi-Fi | No |
Quality of Service (QoS) support | Yes |
Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Ethernet interface type | Fast Ethernet |
Number of languages | 32 |
Alarm input/output | Yes |
Day/night mode | Yes |
Placement supported | Outdoor |
Infrared (IR) cut-off filter | Yes |
Connectivity Technology | Wired |
Wide Dynamic Range (WDR) | Yes |
Type | IP security camera |
Number of Cameras | 1 |
Sample Rate | 48 kHz |
Audio output channels | 1.0 channels |
Audio input channels | 1.0 channels |
Voice Codecs | PCM |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Built-in HDD | No |
Card reader integrated | Yes |
Maximum memory card size | 128 GB |
Composite video out | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Camera tilt control | Yes |
Camera pan control | Yes |
Lens viewing angle, horizontal | 114° |
Lens viewing angle, vertical | 59° |
Lens viewing angle, diagonal | 141° |
Tilt angle range | 0 - 75° |
Camera shutter speed | 1/3 - 1/100000 s |
Angle of rotation | 355° |
Pan range | 0 - 355° |
Minimum illumination | 0 lx |
Sensor type | CMOS |
Number of sensors | 1 |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
Video compression formats | H.265+ |
Gain control type | Auto |
Image quality adjustment | Contrast |
Video streaming | Yes |
Supported graphics resolutions | 352 x 288 |
Noise reduction | Yes |
Maximum Resolution | 2688 x 1520 pixels |
Noise reduction technology | 3D noise reduction |
Highlight Compensation (HLC) | Yes |
Back Light Compensation (BLC) | Yes |
Region of Interest (ROI) encoding | Yes |
Bit rate | 32 Kbps - 16 Mbps |
Frame rate | 30 fps |
Total megapixels | 4 MP |
Night Vision | Yes |
Infra-red wavelength | 850 nm |
LED type | IR |
Night vision distance | 30 m |
Number of lenses | 1 |
Auto focus | Yes |
Focal length range | 2.8 - 12 mm |
Maximum aperture number | 1.4 |
Warnings | Avoid direct contact with water to prevent electrical damage. |
