| Mounting Type | Ceiling/wall |
| Product colour | White |
| I code | IK10 |
| International Protection (IP) code | IP66 |
| Form factor | Dome |
| Housing material | Metal |
| DC output current | 0.9 A |
| Power consumption (Power over Ethernet (PoE)) | 12.5 W |
| DC output voltage | 12 |
| Power consumption (max) | 10.5 W |
| Power source type | DC, PoE |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Video motion detection | Yes |
| Mirror | Yes |
| PASSWORD PROTECTION | Yes |
| Anti-flicker | Yes |
| Security algorithms | EAP-TLS |
| IP address filtering | Yes |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Behavior analysis | Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection |
| Web-based management | Yes |
| Reset button | Yes |
| Weight | 1.29 kg |
| Height | 133.2 mm |
| Diameter | 15.3 cm |
| Number of users | 32 user(s) |
| Bluetooth | No |
| Networking standards | IEEE 802.3af |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Quality of Service (QoS) support | Yes |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Ethernet interface type | Fast Ethernet |
| Number of languages | 32 |
| Alarm input/output | Yes |
| Day/night mode | Yes |
| Placement supported | Outdoor |
| Infrared (IR) cut-off filter | Yes |
| Connectivity Technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Type | IP security camera |
| Number of Cameras | 1 |
| Sample Rate | 48 kHz |
| Audio output channels | 1.0 channels |
| Audio input channels | 1.0 channels |
| Voice Codecs | PCM |
| COMPATIBLE MEMORY CARDS | MicroSDHC |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Maximum memory card size | 128 GB |
| Composite video out | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Camera tilt control | Yes |
| Camera pan control | Yes |
| Lens viewing angle, horizontal | 114° |
| Lens viewing angle, vertical | 59° |
| Lens viewing angle, diagonal | 141° |
| Tilt angle range | 0 - 75° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Angle of rotation | 355° |
| Pan range | 0 - 355° |
| Minimum illumination | 0 lx |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Progressive Scan | Yes |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Video compression formats | H.265+ |
| Gain control type | Auto |
| Image quality adjustment | Contrast |
| Video streaming | Yes |
| Supported graphics resolutions | 352 x 288 |
| Noise reduction | Yes |
| Maximum Resolution | 2688 x 1520 pixels |
| Noise reduction technology | 3D noise reduction |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Region of Interest (ROI) encoding | Yes |
| Bit rate | 32 Kbps - 16 Mbps |
| Frame rate | 30 fps |
| Total megapixels | 4 MP |
| Night Vision | Yes |
| Infra-red wavelength | 850 nm |
| LED type | IR |
| Night vision distance | 30 m |
| Number of lenses | 1 |
| Auto focus | Yes |
| Focal length range | 2.8 - 12 mm |
| Maximum aperture number | 1.4 |
| Warnings | Avoid direct contact with water to prevent electrical damage. |
