Mounting Type | Ceiling |
Weatherproof | Yes |
Product colour | White |
Form factor | Dome |
DC output current | 1 A |
DC output voltage | 12 |
Power source type | DC |
Power consumption (typical) | 12 W |
Anti-flicker | Yes |
Digital watermark | Yes |
PASSWORD PROTECTION | Yes |
Security algorithms | WPA2-PSK |
Operating temperature (T-T) | -30 - 50 °C |
Operating relative humidity (H-H) | 0 - 95% |
Cloud services supported | EZVIZ Cloud |
Cloud-managed | Yes |
Depth | 136 mm |
Weight | 539.7 g |
Height | 140 mm |
Width | 100 mm |
Supported network protocols | EZVIZ Cloud Proprietary Protocol |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Ethernet LAN | Yes |
Channel bandwidth | 20 MHz |
Bluetooth | No |
Wi-Fi | Yes |
Networking standards | IEEE 802.11b |
Certification | CE / UL / RoHS / WEEE / REACH |
Day/night mode | Yes |
Luminous Flux | 0.5 lm |
Placement supported | Outdoor |
Auto-tracking | Yes |
Wide Dynamic Range (WDR) | Yes |
Connectivity Technology | Wireless |
Type | IP security camera |
PACKAGE WEIGHT | 823.6 g |
Package height | 192 mm |
Package width | 140 mm |
Package depth | 140 mm |
Number of Cameras | 1 |
Maximum memory card size | 512 GB |
Built-in HDD | No |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Card reader integrated | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Pan range | 0 - 350° |
Lens viewing angle, diagonal | 108° |
Lens viewing angle, vertical | 48° |
Lens viewing angle, horizontal | 91° |
Tilt angle range | 0 - 80° |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Sensor type | CMOS |
Digital Wide Dynamic Range (DWDR) | Yes |
Video compression formats | H.265 |
Image quality adjustment | DNR |
Maximum Resolution | 2880 x 1620 pixels |
Bit rate | Ultra-HD; Hi-Def; Standard. Adaptive bit rate. |
Night Vision | Yes |
Night vision distance | 30 m |
Lens diameter | 6 mm |
Number of lenses | 2 |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
