| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Draußen |
| transmission technology | Kabelgebunden |
| Virtual Assistant | Amazon Alexa & Google Assistant |
| Eigenschaft | Betriebsanleitung |
| color temperature | 4500 K |
| certification | FCC, CE, UKCA, ERP |
| Design | |
| form factor | Patrone (Form) |
| attachment type | Wand |
| Product color | Schwarz |
| International degree of protection (IP code) | IP66 |
| Camera | |
| minimum lighting | 0 Lux |
| viewing angle (horizontal) | 82.3° |
| viewing angle (vertical) | 52.5° |
| Lens viewing angle, diagonal | 110° |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 2,7 mm (1 / 2.7") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| Maximum f-number | 2,1 |
| Fixed focal length | 4 mm |
| night vision | |
| night vision distance | 20 m |
| LED Type | IR |
| Number of illumination LEDs | 4 |
| Video | |
| Maximum resolution | 3072 x 1728 Pixel |
| total megapixels | 5 MP |
| Supported video formats | H.264, H.265 |
| Supported graphic resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3072 x 1728 |
| Supported video modes | 720p, 1080p |
| Up to 30 frames per second | 25 fps |
| image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
| Audio | |
| Audio-System | 2-Wege |
| Supported audio formats | AAC, PCM |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| mesh standard | IEEE 802.3af |
| Supported network protocols | IP, TCP, UDP, SMTP, FTP, DHCP, RTSP, ONVIF |
| streaming method | Multicasting |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash) |
| Max memory card size | 256 GB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Geräuschpegel der Sirene | 100 dB |
| alert notification type | E-Mail, Schnappschussalarmmitteilung |
| Intelligent Video Surveillance (IVS) system properties | Erkennung von Menschen, Fahrzeugerkennung |
| energy | |
| energy source | PoE |
| Power consumption (max.) | 5 W |
| DC output volts | 12 |
| DC output current | 1 A |
| operating conditions | |
| operating temperatur | -20 - 50 °C |
| Storage temperature range | -20 - 50 °C |
| Operating relative humidity | 10 - 80% |
| humidity during storage | 0 - 90% |
| system requirement | |
| Supported mobile operating systems | Android, iOS |
| weight and dimensions | |
| broad | 66 mm |
| depth | 170 mm |
| height | 66 mm |
| Weight | 342 g |
| packaging type | Box |
| sustainability | |
| Konformitätsbescheinigungen | RoHS |
| scope of delivery | |
| number of cameras | 1 |
| Supplied cables | LAN (RJ-45) |
